Rectangular seal BECA 011 Rod
bronzecarbonPTFE

rectangular seal
rectangular seal
rectangular seal
Add to favorites
Compare this product


Characteristics

Configuration
rectangular
Material
bronze, carbon, other materials, PTFE
Applications
for aircraft
Other characteristics
static, dynamic, hydraulic, large
Temperature limit

Min.: -200 °C
(-328 °F)

Max.: 260 °C
(500 °F)

Pressure limit

Min.: 0 MPa

Max.: 250 MPa

Description

The BECA 011 Rod profile is a back-up ring cut at 30° with a rectangular profile. The ring is systematically assembled in tandem with an O'Ring or an X'Ring. An uncut version of this profile can be made. Advantages Used in static and dynamic applications May be used for alternating and rotating applications Large contact surface area, which protects the O'Ring from deformation caused by pulsating pressures Preferred assembly in a closed groove for profiles cut at 30° Assembly in open groove for uncut profiles Applications Automotive Hydraulic equipment Mobile machinery Machine tools Injection presses Valves Hydraulic cylinders Materials Standard virgin PTFE Filled PTFE (fibreglass, carbon, bronze) Other materials may be used Speed - 2 m/s in alternating or rotating applications Medias - The majority of liquids, or gaseous or chemical fluids.
