DIMENSIONS: 12.33” X 6.125”
HID LAMP POWER:
55W MAX (50W NOMINAL)
78W MAX (75W NOMINAL)
MOTORS AND CIRCUITRY: 100W MAX
VOLTAGE: 28 VDC
LIGHT OUTPUT:
690K CP (FOR THE 75W)
480K CP (FOR THE 50W)
OTHER OUTPUTS AVAILABLE
WEIGHT: 6.5 LBS. MAX
BEAM WIDTH: MULTIPLE OPTIONS AVAILABLE
Capable of being extended at a maximum airspeed of 135 knots. Once extended and in a stationary position, the light is capable of withstanding an air speed of 180 knots.
Light head is able to rotate 360°.
50 w lamp has a 40 times longer lamp life than a standard 200w halogen lamp, 20 times longer for the 75w lamp. Designed to fit the existing MIL-L81174/2B.
