Electric riveting machines

OUR STRONG ALL-ROUNDER The new BA-robot Power RACe owns all the requirements for all aircraft part assemblies. As highly flexible, with an automated positioning system the Power RACe fulfills all requirements ...

... including future designs. This is exactly what the new flexible MPAC riveting system of Broetje-Automation is designed to do. We have put a special focus on the automated drilling and riveting of shells ...

C-FRAME PANEL ASSEMBLY CELL - C-FRAME RIVETING SYSTEM: RESILIENT CLASSIC The C-frame riveting system is the "classic" riveter that can rivet everything from small to large fuselage panels. The model ...

... and adaptable component fastening system Precise positioning of component and riveting system Fully-automated process - all axes are CNC-controlled High-speed riveting process Offline or teach-in programming

... fixtures Component rest on the fixtures during the entire riveting process Precise positioning of the anvils (OR riveting tools) Secure component clamping during processing Gapless riveting ...

VERTICAL PANEL ASSEMBLY CELL - VERTICAL RIVETING SYSTEM: REMAINING CLEAN EVEN WITH CLOSED STRUCTURES Chips and cuttings falling into inaccessible areas pose the main problem with drilling in closed structures. Subsequent ...

... PANEL ASSEMBLY CELL - WING RIVETING SYSTEM: PRECISION FOR WINGS Our wing riveting system meets the highest demands for modern precision drilling and riveting of fuel tight wing structures. Stationary ...

IJAC: INTEGRATED JOINING ASSEMBLY CELL During fuselage assembly, the individual sections are joined to form the complete fuselage. The individual fuselage sections are first loaded into the station. Supported with laser measuring technology, ...

... the FDH walks to position, gets locked with the vacuum cups and is ready to perform the drilling/riveting operation. After drilling/riveting at the current area, the FDH walks one ...
