Machine tool components

Rotational speed: 6,000 rpm
Diameter: 180 mm

ES510 - H6161H1809 TECHNICAL SPECIFICATIONS Body diameter: 180 mm Torque: 38/46 Nm Power S1/S6: 24/28,8 kW Motor Technology: asynchronous Tool Release: Hydraulic Ratered Voltage: 380 V Option encoder: LB 1 Vpp or TTL Poles: ...

Rotational speed: 6,000 rpm
Diameter: 180 mm

TECHNICAL SPECIFICATIONS Body diameter: 180 mm Torque: 48/57 Nm Power S1/S6: 30/36 kW Motor Technology: asynchronous Tool Release: Hydraulic Ratered Voltage: 380 V Option encoder: LB 1 Vpp or TTL Poles: 6 Front/Rear bearings: ...

Rotational speed: 5,300 rpm
Diameter: 180 mm

TECHNICAL SPECIFICATIONS Body diameter: 180 mm Torque: 90/120 Nm Power S1/S6: 50/67,5 kW Motor Technology: synchronous Tool Release: hydraulic Ratered Voltage: 616 V Option encoder: LB 1 Vpp or TTL Poles: 6 Front/Rear bearings: ...

Rotational speed: 5,000 rpm
Diameter: 190 mm

TECHNICAL SPECIFICATIONS Diameter Ø190 Torque S1/S6 95,5/124Nm Power S1/S6 50/65kW ISO50 Synchronous Automatic Hydraulic Tool Release Rated Voltage 540V Encoder LB 1Vpp o TTL Poles 6 Ceramic Bearings Bearings Lubrication ...

Rotational speed: 2,000 rpm
Diameter: 190 mm

TECHNICAL SPECIFICATIONS Body diameter: 190 mm Torque: 124/149 Nm Power S1/S6: 26/31 kW Motor Technology: Asynchronous Tool Release: hydraulic Ratered Voltage: 380 V Option encoder: LB 1 Vpp or TTL Poles: 8 Front/Rear bearings: ceramic Bearings ...

Rotational speed: 3,000 rpm
Diameter: 190 mm

BODY DIAMETER Ø180 - Ø350 ES511 ISO50 - H6161H1835 TECHNICAL SPECIFICATIONS Diameter Ø190 Torque S1/S6 150Nm/202Nm Power S1/S6 47Kw/63Kw ISO50 Synchronous Automatic Hydraulic Tool Release Rated Voltage 566V Encoder ...

Rotational speed: 3,000 rpm
Diameter: 190 mm

BODY DIAMETER Ø180 - Ø350 ES511 - H6161H1642 TECHNICAL SPECIFICATIONS Diameter Ø190 Torque S1/S6 200Nm/241Nm Power S1/S6 63Kw/76Kw HSK A100 Synchronous Automatic Hydraulic Tool Release Rated Voltage 615V Encoder LB 1Vpp o ...

Rotational speed: 18,000 rpm
Diameter: 230 mm

TECHNICAL SPECIFICATIONS Body diameter: 230 mm Torque: 53/64 Nm Power S1/S6: 100/120 kW Motor Technology: Asynchronous Tool Release: hydraulic Ratered Voltage: 380 V Option encoder: LB 1 Vpp or TTL Poles: 4 Front/Rear bearings: ...

Rotational speed: 1,700 rpm
Diameter: 230 mm

TECHNICAL SPECIFICATIONS Body diameter: 230 mm Torque: 191/229 Nm Power S1/S6: 34/41 kW Motor Technology: Asynchronous Tool Release: hydraulic Ratered Voltage: 400 V Option encoder: LB 1 Vpp or TTL Poles: 8 Front/Rear bearings: ...

Rotational speed: 1,000 rpm
Diameter: 310 mm

BODY DIAMETER Ø180 - Ø350 ES518 - H6161H1994 TECHNICAL SPECIFICATIONS Body diameter: 310 mm Torque: 410/493 Nm Power S1/S6: 43/51,6 kW Motor Technology: Asynchronous Tool Release: hydraulic Ratered Voltage: 380 V Option encoder: LB ...

Continuous tilting milling head TILT with motorspindle.

Indexed or continuous vertical milling head TVE with motorspindle.

The BF-line of machines has the main features in the motion of the column to perform the cross movement, the movement of the table for the longitudinal while the vertical axis is performed by the milling head carriage. This configuration ...

DIAMOND LINEAR is a gantry style machining centre with 3 or 5 axis for high speed moulds/dies machining as well as aerospace jobs. It features a monobloc structure with a gantry moving saddle and stationary workpiece. Machine available ...

DIAMOND LINEAR 30 is a gantry style machining centre with 3 or 5 axis for high speed moulds/dies machining as well as aerospace jobs. It features a monobloc structure with a gantry moving saddle and stationary workpiece. Machine available ...

5 axis milling head with torque motors (direct drive) Automatic spindle change

Milling head with continuous 0,001 deg. indexing Spindle speed range 0-5000 rpm

5 axis geared milling head Spindle speed range 0-6000 rpm

The LHS line features a longitudinally moving column. It is a medium / large size machining centre with 3 or 5 machining axis. Due to its structure, the machine is suitable for various applications : with moving rotary table, with automatic ...

M5S The M5S features a cast iron body and symmetrical fork structure providing optimal thermal stability. The two tandem motors solution for controlling the A and C axes guarantees an absence of backlash and is maintenance-free. High ...

UAD TECHNOLOGY Indexing heads that are ideal for all types of machining operations, including large stock removal, hard materials, long tools and long 3D finishing operations, etc. This technology is applied in two different geometries: Universal ...

E5E TECHNOLOGY Head with two continuous axes, ideal for machining with 4 or 5 continuous axes, as well as for super finishing operations in 3+2 axes. We offer 3 electro-spindles with different torque-power specifications designed for ...
