AC/DC power supply LPU1009
for lighting

AC/DC power supply
AC/DC power supply
AC/DC power supply
Add to favorites
Compare this product


Characteristics

Type
AC/DC
Applications
for lighting
Input voltage

115 V

Output voltage

28 V

Current

4.8 A

Description

LPU1009 Light Power Unit Description Light Power Unit, designed for various aircraft Key features Electrical LPU provides stabilized / regulated DC power 2x PWM and 2x RS485 interfaces communicates through customized software protocol (RS485 interface) Mechanical built-in over current and over-temperature protection fully qualified acc. to RTCA-DO160 robust anodized aluminum housing Other eliminates need of TRU power customized output configuration on request MTBF 25,000 OH Technical data Mechanical dimensions length: 220 mm (235 mm with receptable) width: 170 mm height: 54.5 mm weight: less than 1.8 kg Electrical data input voltage: 115 V AC / VF 360 - 800 Hz input current: 4.8 A output voltage: 28 V DC output power: max. 400 W
