Airliner autopilot DFC110

Overview
The Avidyne DFC110 brings the precision, stability, and intuitive operation of the DFC autopilot family to Vantage-equipped Cirrus aircraft, with integrated VNAV capability. Built on the proven DFC90 platform, the DFC110 is an attitude-based digital autopilot that uses the aircraft’s all-digital air data and attitude/heading reference system to deliver smooth, stable, and accurate flight control. Compared to older rate-based systems, it reduces overshoots, hunting, and flutter during instrument procedures and in changing wind conditions.

Mode Awareness and Interface
Backlit controls indicate armed and engaged modes. Flight director and autopilot indications are shown directly on the flight displays for continuous mode awareness throughout all flight phases.

Key Features

• Full capability set of the DFC90 Digital Autopilot with added VNAV support.
• Designed for Cirrus aircraft equipped with Vantage and dual IFD navigators.
• Attitude-based digital autopilot for improved stability, accuracy, and reliability.
• Supports lateral and vertical modes: Flight Director, Altitude Hold, Airspeed Hold, Vertical Speed Hold, Heading, Navigation, Approach, LOC/GS, and VNAV.
• Integrates with the PFD/MFD all-digital Air Data and Attitude/Heading Reference System.
• "STRAIGHT & LEVEL" button recovers the aircraft from unusual attitudes by overriding autopilot modes and leveling pitch and roll.
• Slide-in replacement path for existing DFC90 and legacy S-TEC 55 autopilots.
• Up to 2-Year Limited Warranty.

Applications
Intended for installation in Vantage-equipped Cirrus aircraft; provides an upgrade path from legacy autopilots and integration with modern glass flight displays and dual IFD navigators.

Documentation
Documentation and manuals: Coming Soon (manufacturer documentation tab indicates materials will be made available).

Specifications

• Model number (page): 850-00170-100
• Commercial designation: DFC110
• Built on: DFC90 platform
• VNAV support: Yes (when paired with Vantage 12.1.0 or later and dual IFD navigators running IFD 10.3.3.2 or later)
• Dimensions: Width: 6.25" (159 mm); Height: 1.5" (38 mm); Depth: 10.6" (279 mm)
• Weight: 2.02 lbs (0.92 kg)
