Barometric pressure sensor CS106
Vdcfor aircraftfor the aerospace industry

barometric pressure sensor
barometric pressure sensor
barometric pressure sensor
Add to favorites
Compare this product


Characteristics

Pressure type
barometric
Output signal
Vdc
Applications
for aircraft
Domain
for the aerospace industry
Pressure range

Min.: 0.5 bar (7.25 psi)

Max.: 1.1 bar (15.95 psi)

Temperature range

Min.: -40 °C (-40 °F)

Max.: 60 °C (140 °F)

Description

Overview The CS106, manufactured by Vaisala, measures barometric pressure for the range of 500 to 1100 mb. This range equates to from below sea level (as in a mine) to over 15,000 feet above sea level. Designed for use in environmental applications, the CS106 is compatible with all Campbell Scientific dataloggers. Benefits and Features Optimized to mount in Campbell Scientific enclosures Integral switching circuit limits power consumption to measurement cycle Three-year warranty Technical Description The CS106 uses Vaisala’s BAROCAP silicon capacitive sensor to measure barometric pressure. It is encased in a plastic shell (ABS/PC blend) fitted with an intake valve for pressure equilibration. The CS106 outputs a linear signal of 0 to 2.5 Vdc, which allows the barometer to be directly connected to a Campbell Scientific datalogger. An internal switching circuit allows the datalogger to power the CS106 only during measurement, which reduces power consumption. Specifications -NOTE- - 1 hPa = 1 mBar Pressure Range - 500 to 1100 hPa Long-Term Stability - ± 0.1 hPa per year Settling Time - 1 s to reach full accuracy after power-up Response Time - 500 ms to reach full accuracy after a pressure step Output Voltage - 0 to 2.5 Vdc Supply Voltage - 10 to 30 Vdc

Catalogs

CS106
CS106
2 Pages
