SRD Vision is a security option for security revolving doors. It features an optical sensor integrated in the ceiling and a sensor control box. The system reliably detects whether no one, one or more people are present in the door. This allows for accurate separation and hence guarantees top-level access security. SRD Vision is suitable for retrofit without modification of the floor structure. It functions with 3-leaf and 4-leaf models.
Product Details
Suitable for 3- and 4-leaf models (rotary cycles 120° and 180° respectively)
Possible bidirectional operation
Inside diameter ranging between Ø1,800 mm and Ø2,500 mm
Passage heights ranging between 2,300 mm and 2,900 mm
No modification of the floor structure needed
Can be retrofitted for all security revolving doors with corresponding dimensions (except for Geryon SRD-S01 with glass ceiling) with a passage height of 2,300 mm or higher
Unaffected by extraneous light
Evaluation unit is suitable for remote maintenance
Passage rate with SRD Vision remains at high level
No risk of people becoming trapped during power failure (automatic, self-monitored set-up of the unit after power is restored)
