Towed fuel bowser

dieselavgasJet A-1

Product Overview
Fully bunded highway aviation bowser designed for secure storage and road transport of Avgas and Jet A-1. Suited to small- and medium-scale refuelling operations at airfields, flying clubs and remote aviation facilities.

Key Features

• 110% bunded construction with stainless steel inner tank
• Tough steel outer structure with roll-over protection frame
• Designed and built in accordance with CAA guidance and current regulations
• Certified for use with Avgas and Jet A-1

Standard Specification

• Fully baffled stainless steel inner tank with bolted manway access
• Stainless steel outer construction incorporating rollover protection and lifting eyes
• Lockable cabinet with roller shutter door for access to dispensing and filtration equipment
• Galvanised tubular steel chassis with rear bumper and galvanised mudguards
• 3500 kg hitch with overrun brake linkage, handbrake and heavy-duty jockey wheel
• 1800 kg auto-reverse braked axles with 205 R16 wheels and tyres
• 4 lifting eyes for safe lifting and on-site handling
• Compliant trailer lighting system with side marker lights and 7‑pin plug
• Rotary tank contents gauge
• Spring-rewind earth bonding reel with controlled retraction
• Collins Youldon manway for inspection with pressure-vacuum vent and turnover valve
• Full ADR tanker approval and certification
• GPI HP-100 sump pump
• GPI HP-100 priming / backup pump
• Stainless steel spring-rewind hose reel, 11 m x 1" Elaflex HD25 aviation refuelling hose
• Fill-Rite 901 1½" flow meter with non-resettable totaliser
• ZVF 25 non-auto aviation fuel dispensing trigger with mesh strainer

Optional Extras

• High-flow diesel engine centrifugal pump with electric start
• 12 V ATEX-approved fuel pump, flow rate up to 57 litres/min
• GPI HP-100 aluminium-bodied dual-action hand pump

Technical Specifications

• Capacity: 2,000 litres
• Length: 3,959 mm
• Width: 1,810 mm
• Height: 1,980 mm
• Empty Weight: 1,425 kg
• Full Weight: 3,025 kg
• Maximum Hose Length: 12 m
