Planer-thicknesser finishing machine M.M.9400

polishinggrindingautomatic

Introduction
The M.M.9400 combined with the PE128 mounting is a compact grinder-polisher designed for producing reference faces and precise thicknessing of flat parts. It offers ergonomic controls, reinforced rigidity and compatibility with a broad range of platens and accessories.

Key details

• Plate diameter: 381 mm (Ø 400 mm optional)
• Plate rotation speed: 20–120 rpm
• Inner ring diameter: 140 mm
• Number of rings: 3 — capacity per ring: 1 part Ø130 mm or 170 parts Ø5 mm
• Motor power: 0.75 kW — Electrical supply: 230 V single-phase
• Weight (without plate): 75 kg — Dimensions (W×H×D): 625 × 720 × 365 mm

Versatility
The M.M.9400 accepts cast iron, DIALAM®, NEW LAM® M’M’ and FAS® platens to achieve finishes from honing to polishing. It is suitable for maintenance and lapping of sealing parts (valves, small mechanical seals, flaps) and can be adapted with dedicated holders for thin samples.

New configuration and improvements

• Rigid welded tubular steel chassis and stainless-steel tank
• Ergonomically improved controls and better screen visibility
• 4.3" touchscreen with memory for 30 recipes and USB import/export
• Multiple accessory attachment points (dosing devices, jib, holders)
• Mobile water inlet controlled by a solenoid valve
• Improved connectivity: control for up to 3 dispensers and remote maintenance capability

Accessories (selection)

• Peristaltic and Venturi dosing units (types 709, 710, 719; M.M.909 / M.M.909 HV)
• Support cabinet (height 73 cm, 1 door, 2 shelves)
• MESUREO material-removal measurement system with wireless probe and real-time display
• Autolapping rings: cast iron, SPYLAP® ceramic, plastic (for Ø 381 mm)
• Rings and sample holders for thin sections (PE128 set)

Downloads
Technical data sheet (PDF) available with full specifications and accessory list.

Technical data (in detail)
Plate Ø: 381 mm (Ø 400 mm optional)
Inner ring Ø: 140 mm
Capacity per ring: 1 part Ø130 mm or 170 parts Ø5 mm
Number of rings: 3
Electric power supply: 230 V single-phase
Motor power: 0.75 kW
Control: 4.3" touchscreen
Plate rotation speed: 20–120 rpm
Dimensions (W×H×D): 625 × 720 × 365 mm
Weight (without plate): 75 kg
Abrasive distribution system: optional
Reference: 10 09400 00

Technical specifications

• Model: M.M.9400 with PE128 mounting
• Intended use: pre-polishing, thicknessing and lapping/polishing of flat surfaces
• Interchangeable platens: cast iron, DIALAM®, NEW LAM® M’M’, FAS®
• User interface: 4.3" touchscreen, 30 recipe memory, USB import/export
• Connectivity: control of up to 3 dosing units and remote maintenance
• Optional tools: MESUREO system, various lapping rings and accessory supports
• Power supply: 230 V single-phase — Motor: 0.75 kW
• Commercial reference: 10 09400 00
