Automated explosives detection system for checkpoint screening
The ACX 6.4 automated checkpoint X-ray system blends Leidos’ proven explosives detection with high-clarity imaging. It offers checkpoint security capabilities that integrate into your current security operations and footprint.
The affordable ACX 6.4 scans bags, briefcases, backpacks, packages, and other small to medium-sized, handcarried objects with simultaneous X-ray imaging and explosives detection technology. It can automatically pinpoint explosives and other potential threats, allowing operators to respond quickly and appropriately. Available in three conveyor lengths and with an optional automated bin return system (BRS), the ACX 6.4 accommodates diverse space requirements and strengthens security while raising the efficiency and convenience of checkpoint security for both operators and the public.
APPLICATIONS
› Automated explosives detection
› Weapons detection
› Contraband detection
› Theft prevention
› Regulatory compliance/inspection
COMPLIANCE
› TSA Air Cargo Qualified
› CE, UL-61010-1
› Radiation Safety: U.S. 21 CFR
1020.40
CERTIFICATION
› ISO 9001:2008
› ISO 14001:2004
GENERAL
Height: 1312 mm (51.7")
Width: 862 mm (34.0")
Length:
Short conveyor: 1700 mm (67.0")
Medium conveyor: 2236 mm (88.0")
Long conveyor: 3030 mm (119.3")
Tunnel Opening:
640 mm (25.2”) W x 430 mm (16.9") H
Conveyor Height:
775 to 835 mm (30.5” to 32.9")
Power Requirements:
1Ø 100-240 VAC ±10% 50/60 Hz ±1%
1.0 KVA max
