Aircraft label printer LM-3000PRO

for airportfor the aerospace industryidentification label

Overview
The LM-3000PRO cable marker printer delivers high-resolution, high-speed identification for cable, terminal block and panel marking. It features an integrated cutter with adjustable half-cut depth, broad consumable compatibility and LETATWIN PC EDITOR PRO for CSV import and Excel copy/paste to enable sequential numbering and batch printing.

Applications

• Cable identification
• Terminal block marking
• Panel and equipment ID labelling
• Heat-shrink marker application

Key features

• Print resolution: 300 DPI
• Print speed: up to 80 mm/sec
• Thermal transfer print technology
• Integrated cutter: auto half cut and manual full cut; adjustable half-cut depth
• Optional double-sided printing and vertical/reverse printing modes
• Connectivity: USB, wired LAN and wireless LAN (IEEE802.11 b/g/n — 2.4 GHz for 802.11n)
• On-demand custom cable markings and batch/sequence printing (sequential numbering)
• Included LETATWIN PC EDITOR PRO: CSV import, Excel copy/paste, sequential numbering and marker editing
• Wide consumable support: grip sleeves, grip tubes, cable tags, conductor markers, heat shrink, terminal block slide plates, PVC tube and self-adhesive tape
• Grip Sleeve design secures wire at three points for anti-rotation and flat printing for clearer text; process faster than conventional heat-shrink
• Multiple platen rollers and attachments supplied for different consumables and tube diameters

Consumables (examples)

• Grip Sleeves
• Grip Tubes
• Cable Tags
• Conductor Markers
• Heat Shrink
• Terminal Block Slide Plates
• PVC Tube
• Self-Adhesive Tape

Included accessories (pack contents)

• Ink Ribbon (LM-IR3015B) and ink ribbon cassette
• Reel stand
• Quick reference manual and safety guidance
• Platen rollers (3 types: for LM-SL34, LM-SL37 and standard)
• Attachments (6 types) covering block markers, a range of tube diameters (e.g. Ø0.8, Ø1.5–Ø2.0, Ø10.0) and ID plates
• Power cable and USB cables
• Manual guide and software use license

Support & training

• Online training resources and instructional videos available
• Technical documentation and product data sheets published for consumables (e.g. Grip Sleeve, Grip Tube)

Technical specifications

• Print resolution: 300 DPI
• Material width: 36 mm
• Maximum print width: 19 mm
• Print speed: 80 mm per second
• Print technology: Thermal transfer
• Cutting function: Auto half cut, manual full cut (half cut: adjustable depth)
• Maximum output range (examples): Grip Sleeves 100 m, Tubes 100 m, Tape 5 m, Marker Strips 5 m, Blocker Markers 1,000, ID Plate 20 m
• Supported OS: Windows 11
• Print options: Double sided; Vertical / Reverse
• Weight: 11 kg (excluding accessories and power cord)
• Dimensions: 427 (W) x 256 (D) x 301 (H) mm
• Connectivity: USB, wired LAN, wireless LAN (IEEE802.11 b/g/n; n = 2.4 GHz only)
• Power supply: AC 100-240 V, 50/60 Hz
