Electric actuator 290
linearfor aircraftball screw

electric actuator
electric actuator
Add to favorites
Compare this product


Characteristics

Type
electric
Movement
linear
Applications
for aircraft
Technology
ball screw
Stroke

7.75 in, 8 in

Torque

6,670 Nm
(4,919.54 ft.lb)

Description

The Model 290 is one of the highest performance linear servo actuators available on the market. We offer this actuator with a digital communications interface. It provides 1,500 lbf at 0.26 inches / second for up to 7.75 inch strokes. It has a homing sequence that determines end of travel on startup, thus, ensuring proper positioning along its stroke. These features allow our customer flexibility to have a drop-in servo actuator for their system. Features Integrated position servo loop control utilizing Moog RS-485 digital communications protocol Non-jamming mechanical stops Stainless steel gear train Precision ball screw and nut assembly Brush-type permanent magnet motor design with integrated holding brake Electrical stops software controlled High resolution magnetic encoder Telemetry is composed of position, temperature, voltage and current Low latency Custom tunable performance parameters
