Design software eHS

simulationfor aeronauticsreal-time

eHS is a generic and reprogrammable FPGA-based electrical solver at the heart of the eFPGASIM suite. eHS provides a convenient user interface enabling users to bring in real-time models created in the simulation tool of their choice: SimScape Power System Simulink toolbox, PSIM, PLECS Blockset, or Multisim. Easily Bring Power Electronics Models to Real-Time Simulation OPAL-RT’s new Schematic Editor is an intuitive user interface for building power electronics and is a part of eHS. It provides an advanced graphical editor and is integrated with OPAL-RT’s & NI’s real-time simulation platforms. Design power electronics models with ease through drag and drop components Interact with a streamlined GUI, and a fast simulation workflow to bring models to real-time simulation Manage analog and digital I/O assignment through the interface Accurate and Precise Electric Machine Real-Time Simulation Integrated within eHS, the FPGA Electric Machine Library is the ideal platform for designing and testing controller and power electronics and electric drive systems. The library includes a power electronic and motor library that lets you simulate all components forming the electrical motor drive system. It includes detailed mathematical model of different type of electrical motors such as: Permanent Magnet Synchronous Machine (PMSM – IPM – BLDC- SPM) Induction Machine (DFIG – DFIM – Squirrel Cage Induction Machine) Switched Reluctance Machines This Hardware-in-the-Loop demo consists of an inverter controller for grid-connected solar energies and an OP4510 real-time simulator. The controller, developed by the GREENLAB of Hefei University of Technology,
