Horizontal balancing machine PHY series

electricbelt-drivenfor the aerospace industry

This machine is mainly suitable for dynamic unbalance detection of various automobile turbocharger rotors. - Balancing machines for turbocharger impellers - Balancing machines for turbocharger compressors - Balancing machines for turbocharger turbines - Auto-positioning bed, large tool carriage structure - Dedicated bracket driven by Nylon belt variable speed motor 230W Features: - Adopt belt drive, hard-bearing brackets - Windows 7/10 operating system, 17” LCD screen - Easy to install and remove, quick to start - Stepless speed regulation Technical data at a glance: PHY-1.6 | PHY-5 | PHY-16 ---|---|--- Max Mass of Workpiece (kg) | 1.6 | 5 | 16 Max Diameter of Workpiece (mm) | Φ00 | Φ300 | Φ300 Distance between Two Support Bearings (mm) | 60~400 | 60~400 | 60~400 Journal Diameter Scope of Workpiece (mm) | Φ5~40 | Φ5~40 | Φ5~40 Diameter Scope of Driving Belt (mm) | Φ15~150 | Φ15~150 | Φ15~150 Rotational Speed when the Diameter of Driving Belt is 100mm (r/min) | 1470 | 1470 | 1470 Motor Power (kw) | 0.2DC | 0.2DC | 0.2DC Min Achievable Residual Unbalance Amount (emar) | 0.15g · mm/kg | 0.15g · mm/kg | 0.15g · mm/kg
