Titanium alloy rod Ti-45Nb
wireaerospaceAMS

titanium alloy rod
titanium alloy rod
titanium alloy rod
titanium alloy rod
titanium alloy rod
titanium alloy rod
Add to favorites
Compare this product


Characteristics

Form
rod, wire
Other characteristics
aerospace, AMS
Mechanical resistance

Min.: 414 MPa

Max.: 448 MPa

Typical elongation

10 %

Diameter

Min.: 2.4 mm
(0.094 in)

Max.: 6.2 mm
(0.244 in)

Description

Ti-45Nb alloy is a kind of single phase titanium alloy material specially used in manufacture of fasteners, which is of higher tensile strength, shear strength and so on comprehensive mechanical properties, good processing performance and corrosion resistance. Due to smaller electric potential difference with composite material and good riveting performance, Ti-45Nb rivets are used by a lot of on civil & military aircraft in USA and Europe, successfully replacing pure titanium rivets and widely used in riveting of composite material. At present, WST can supply Ti45Nb straight or coiling wires in size of dia.2.4mm to dia.6.2mm according to AMS 4928D specification.
