Runway baggage trailer
with tarpaulinaluminum

runway baggage trailer
runway baggage trailer
runway baggage trailer
runway baggage trailer
runway baggage trailer
runway baggage trailer
runway baggage trailer
Add to favorites
Compare this product


Characteristics

Applications
for runway
Other characteristics
with tarpaulin, aluminum
Carrying capacity

14 t
(15 us ton)

Description

Reinforced frame construction for 14 t point load over 3 m at centre of gravity Fixed aluminium hollow profile front wall with 2 full-height centre supports Aluminium hollow profile rear wall, internally riveted frame, foldable, with Kinnegrip double locking Double floor consisting of subfloor with integrated steel omega profiles beneath resin-coated wear floor (stacker axle load: 5,460 kg) Aluminium hollow profile side walls, 1,000/25 mm, with Kinnegrip double locking Installation of axles from well-known manufacturers such as SAF or BPW OPTIONAL: Smooth steel plate floor or steel stud plate floor, tack-welded to external frame OPTIONAL: Perforated external frame with approx. 100 mm hole spacing, 50/30 mm slot, for securing 2 t per lashing point OPTIONAL: Reinforced body with load securing certified according to DIN EN 12642 Code XL OPTIONAL: Weather-resistant larch or hardwood floor, 40 mm, with top-hat profile over side members, without secondary floor OPTIONAL: Cement cover consisting of roof arches inserted directly into the central and rear corner posts OPTIONAL: Pull-out drawbar, max. 600 mm adjustment, with Getofix drawbar support TYPE DESIGNATION 2-AXLE PLATFORM TRAILER - BUILDING MATERIALS WEIGHTS Gross weight (techn.): 18 t Tare weight: approx. 3. 6 t DIMENSIONS Internal platform length: approx. 7,100 mm Internal platform width: approx. 2,480 mm Total width: 2,550 mm Loading height, unladen approx. 1, 35 0 mm, clearance between tyres and frame at front approx. 13 0 mm Frame height at front approx. 1 60 mm
