6 - 10 Pers. helicopter 407GXi

passenger transportbusinessrescue

Overview
The Bell 407 is a single-engine, four‑blade light utility helicopter with a configurable cabin and an IFR-certified flight deck. The type has accumulated more than six million global flight hours and is used across public safety, utility, HEMS, corporate transport, armed multi-role and training operations.

Missions

• Public safety: law enforcement, firefighting, search and rescue
• Utility: external load capability and access to confined or remote sites
• HEMS: stable platform with bi-fold doors for patient loading
• Corporate transport: cabin layout for up to six passengers with wide cabin door
• Armed multi-role: Bell 407M configuration for tactical/armed missions
• Training: glass cockpit suitable for pilot instruction and situational awareness

Key Features

• Precise Flight Pulselite®: pulsed landing and taxi lights to improve external visibility and reduce bird strikes (standard on 407 GXi and available aftermarket)
• IFR-capable: instrument flight operations in lower cloud ceilings
• High-resolution LED displays with improved readability and faster processors
• Custom cabin space: easy entry, seating for six passengers and >100 cu ft of flexible passenger area
• Powerplant: Rolls‑Royce Model 250‑C47E/4 turboshaft with dual-channel FADEC and auto-light features
• Maintenance support: composite rotor blades without life limit and Health and Usage Monitoring for real-time updates

Avionics & Systems
Integrated GARMIN G1000H® NXi flight deck with synthetic vision and terrain awareness. Features include wireless connectivity via Flight Stream 510 for flight plan sync and database uploads, moving map on HSI, multi-pane MFD capability, power situation indicator, fuel flow and range ring mapping, tail rotor camera display on MFD, and optional WireAware, ADS‑B out/in, radar altimeter, TAS/TCAS I traffic and XM Weather.

Performance highlights

• Capacity: 1 + 6 (pilot + 6 passengers)
• Max cruise: 133 kts / 246 km/h
• Range at VLRC: 337 nm / 624 km
• Max endurance: 4.0 hrs
• Hover ceiling (IGE): 13,550 ft
• Hover ceiling (OGE): 11,940 ft

Technical specifications

• Standard seating: 1 + 6
• Standard fuel: 127.8 US gal / 482.8 liters
• Aux fuel: 19 US gal / 71.9 liters
• Cabin volume: 85 ft³
• Aft baggage compartment volume: 16 ft³ / 0.5 m³
• Empty weight (Base 407GXi aircraft): 2,700 lbs / 1,224 kg
• Max gross weight (internal, standard): 5,000 lbs / 2,268 kg
• Max gross weight internal (optional): 5,250 lbs / 2,381 kg
• Max gross weight (external load): 6,000 lbs / 2,722 kg
• Useful load - internal (standard, Base 407GXi spec): 2,300 lbs / 1,043 kg
• Useful load (internal, optional, Base 407GXi): 2,550 lbs / 1,156 kg
• Cargo hook capacity: 3,100 lbs / 1,406 kg
• Powerplant takeoff: 862 SHP / 643 kW
• Powerplant max continuous: 761 SHP / 567 kW
• Engine: Rolls‑Royce Model 250‑C47E/4 turboshaft with dual digital FADEC
