Ball nose milling cutter SilverLine

corner radiuswith TiAlCrN coatingcarbide

Overview
SilverLine solid carbide end mills provide a universal solution for machining steel, stainless steel and cast iron (ISO P / M / K). The family combines a reinforced core, optimised geometries and the DPB72S TiAlCrN multilayer coating to ensure stable cutting performance across a wide range of milling operations.

Product range

• Square end mills
• Corner chamfer end mills
• Torus face end mills
• Ball nose end mills
• Corner radius end mills
• 2-, 3-, 4-, 5-, 6-, 7- and 9-flute designs (metric 2/3-flute; imperial 7/9-flute availability)

Size availability

• Extensive imperial sizes for US machining
• Selected metric configurations
• Diameter coverage from selected geometries Ø 3 mm up to 25 mm and Ø 1/8"–1 1/4"

Milling capabilities / Main applications
SilverLine supports a wide range of universal milling strategies. Typical applications include:

• Shoulder milling
• Face milling
• Peripheral milling
• Helical ramp milling and helical plunging
• Slot milling and full-slot operations
• Trochoidal milling
• Roughing and roughing-finishing
• High-accuracy finishing
• 3D milling with ball nose and radius geometries
• Deburring

Design & performance highlights

• Reinforced core for improved rigidity and reduced vibration
• Optimised flute geometry and relief angles to reduce heat and increase cutting efficiency
• Special cutting geometries for smooth operation at high cutting speeds across roughing, full-slot, peripheral and finishing tasks
• Enhanced chip evacuation for consistent process reliability
• Manufactured with Latest Edge Prep technology: individual CNC-controlled brushing per tool for consistent edge condition

Material suitability
Primary applications: steel, stainless steel and cast iron (ISO P / M / K). Secondary applicability to selected non-ferrous and heat-resistant materials depending on geometry.

Demonstrations
Tools validated under representative machining conditions demonstrate reduced cutting forces and extended tool life in production scenarios.

Technical specifications

• Denomination: SilverLine (CERATIZIT Advanced Lines family)
• Base material: premium solid carbide substrate
• Coating: DPB72S — TiAlCrN multilayer coating with chrome enhancement
• Geometries: multiple flute counts (2–9) and edge types (sharp, radius, chamfer, torus, ball nose)
• Core design: reinforced for enhanced process reliability
• Manufacturing: Edge Prep technology with CNC-controlled brushing per tool
• Versions: short, medium, long, extra-long; imperial and metric options
• Size range: selected geometries from Ø 3 mm to 25 mm and Ø 1/8"–1 1/4"
• Applications: shoulder, face, peripheral, helical ramp, slot, trochoidal, roughing, finishing, 3D milling, deburring
• Material groups: ISO P / M / K (primary); non-ferrous and heat-resistant materials (secondary)
