Overview
The Continental® 200 Series (including O-200 and IO-240 variants) is a family of 4-cylinder, air-cooled AvGas engines widely used in training, recreational and light-sport aircraft. The series is engineered for straightforward installation, predictable performance and serviceability across common general-aviation platforms.

Key design features

• Tuned induction on IO-240 for improved cylinder-to-cylinder intake-air distribution and enhanced fuel efficiency
• O-200 rated at approximately 100 continuous HP at 2750 RPM (typical 200 Series performance)
• Air-cooled, naturally aspirated four-cylinder architecture for simplified maintenance and weight efficiency

Applications

• Primary and advanced flight training aircraft
• Recreational, touring and light-sport aircraft
• Common installations: Vashon Ranger R7 (O-200), CubCrafters Carbon Cub EX (O-200), Diamond DA20-C1 (IO-240)

Manufacturing and quality
200 Series engines are produced and tested under Continental® quality control standards at the company facility in Mobile, Alabama, with traceable inspection and acceptance testing to support reliability in service.

Technical data (summary)

• Certified fuels: 80/87 and 100/100LL AvGas
• Engine type: 4-cylinder, gasoline, spark-ignition, four-stroke (carbureted for O-200; IO-240 with tuned induction)
• Cooling: Air cooled, naturally aspirated
• Propeller rotation: Tractor right (clockwise) typical
• Turbocharged: No
• Maximum rated RPM: ~2750–2800 r/min depending on model

Highlighted notes

• Compression ratios: typical examples 7.0:1 (O-200) and 8.5:1 (O-200D, IO-240)
• IO-240 offers tuned induction to improve intake-air distribution and smoothness
• Proven service history powering well-known light-aircraft types

Technical specifications

• Models: O-200, IO-240 (and related O-200 A & B, O-200-D)
• Bore: 103.19 mm & 112.7 mm (4.062 in & 4.438 in)
• Stroke: 98.4 mm (3.875 in)
• Length: 666–739 mm (26.22–29.10 in)
• Height: 589–667 mm (23.18–26.25 in)
• Width: 798–802 mm (31.4–31.56 in)
• Displacement: 3292–3928 cm³ (201–240 in³)
• Rated power: 75–93 kW (100–125 HP) depending on model
• Dry weight: 89.3–131.2 kg (196.8–238.2 lbs) depending on model
