Fuel tank

rigidfor aircraftstainless steel

Overview
Compact all-steel bunded fuel tank designed for safe storage and transport of diesel. Fuelcube 110 US gal is UL142 certified and UN approved for highway transport, suitable for refuelling plant, generators and site equipment.

Certification
CERTIFIED UL 142 STANDARD FOR SAFETY — STEEL ABOVEGROUND TANKS FOR FLAMMABLE AND COMBUSTIBLE LIQUIDS

Features

• Pressure-tested inner tank
• Strainer fitted to remove dirt and debris
• 2" filling point for tanker deliveries; 3" filling point for splash filling
• ½” BSP generator feed and return connections
• ¼" pressure relief valve
• ½" BSP bund drain socket
• Rotary fuel level gauge
• Shot blasted to SA 2.5 and painted in 2-pack polyurethane finish
• Secure lockable lid with anti-vandal door and internal hinges; lid opens with gas strut
• Compact, stackable design
• 4 × galvanized lifting eyes and forklift pockets for safe lifting — can be lifted full
• Limited tank warranty

Product information

• 110-gallon capacity US fuel tank for diesel use
• All-steel construction, 13 gauge
• UN approved for highway transport of diesel
• 110% bunded containment
• Compliant with current regulations
• Suitable for refuelling small plant, groundcare equipment, generators and traffic control equipment

Fuel dispensing options

• FC010 DISPENSING KIT — High-flow hand pump, 10 ft hose & manual trigger
• FC050 DISPENSING KIT — 12/24V battery pump, 10 ft hose & auto shut-off trigger

Technical information
Length | 30.86 in (784 mm)
Width | 40.31 in (1,024 mm)
Height | 50.47 in (1,282 mm)
Empty Weight | 705 lb (320 kg)
Full Weight | 1,471 lb (667 kg)
Maximum Hose Length | 16 ft (5 m)
Steel Thickness | 13 Gauge

Characteristics / spécifications techniques

• Model: Fuelcube
• Capacity: 110 US gallons
• Construction: All-steel, 13 Gauge steel thickness
• Bunding: 110% bunded
• Certifications: UL142 certified; UN approved for highway transport of diesel
• Inner tank: Pressure tested
• Filling points: 2" for tanker deliveries; 3" for splash filling
• Connections: ½” BSP generator feed and return; ½" BSP bund drain socket
• Pressure relief: ¼" pressure relief valve
• Gauge: Rotary fuel level gauge
• Finish: Shot blasted to SA 2.5 and painted in 2-pack polyurethane
• Handling: 4 × galvanized lifting eyes and forklift pockets; stackable design
• Weights: Empty 705 lb (320 kg); Full 1,471 lb (667 kg)
• Dimensions (L×W×H): 30.86 in × 40.31 in × 50.47 in (784 mm × 1,024 mm × 1,282 mm)
• Maximum hose length: 16 ft (5 m)
• Dispensing kits available: FC010 (manual high-flow), FC050 (12/24V battery pump with auto shut-off)
