Towed fuel bowser

avgasJet A-1electric

Overview
Used and trusted by thousands, our bestselling Fuelcube is the perfect compact fuel tank. Ideal for any small to medium application, these all-steel 110 gallon fuel tanks are 110% bunded, U.L. certified and U.N. approved to transport diesel on the highway. Super-tough and secure, they give you fast easy access to fuel on-site, or across multiple sites. Any time, any place.

Certification
CERTIFIED UL 142 STANDARD FOR SAFETY — STEEL ABOVEGROUND TANKS FOR FLAMMABLE AND COMBUSTIBLE LIQUIDS.

Features

• Pressure tested inner tank
• Fitted with strainer to remove dirt and other debris
• 2" filling point for tanker deliveries, 3" filling point for splash filling
• ½” BSP generator feed and return connections
• ¼" pressure relief valve
• ½" BSP bund drain socket
• Rotary fuel level gauge
• Shot blasted to SA 2.5 and painted in 2-pack polyurethane finish

Fuel dispensing options

• FC010 DISPENSING KIT — High-flow hand pump, 10ft hose & manual trigger
• FC050 DISPENSING KIT — 12/24V Battery-powered pump, 10ft hose & auto shut-off trigger

Product information

• 110-gallon capacity US fuel tank, suitable for use with diesel
• All-steel construction for unrivaled strength and security
• U.N. approved for transporting diesel on the highway
• 110% bunded
• Fully compliant with current regulations
• Ideal for refueling small plant and machinery, groundcare equipment, generators and traffic control equipment
• Secure lockable lid with anti-vandal door and internal hinges
• Lockable lid opens with gas strut for improved access
• Compact and stackable design
• 4 x galvanized lifting eyes and forklift pockets for safe lifting/moving
• Fuelcube can be lifted full of fuel using the lifting eyes or forklift pockets
• Limited tank warranty for peace of mind

Technical information
Length: 30.86 in (784 mm)
Width: 40.31 in (1,024 mm)
Height: 50.47 in (1,282 mm)
Empty Weight: 705 lb (320 kg)
Full Weight: 1,471 lb (667 kg)
Maximum Hose Length: 16 ft (5 m)
Steel Thickness: 13 Gauge

Caractéristiques / spécifications techniques

• Capacity: 110 US gallons (diesel)
• Construction: All-steel, 13 gauge
• Bunding: 110% bunded
• Certifications: UL 142 certified; U.N. approved for highway transport of diesel
• Connections: ½” BSP generator feed and return
• Filling points: 2" for tanker deliveries; 3" for splash filling
• Relief valve: ¼" pressure relief valve
• Bund drain: ½" BSP bund drain socket
• Gauge: Rotary fuel level gauge
• Finish: Shot blasted to SA 2.5 and painted in 2-pack polyurethane
• Dimensions (L×W×H): 30.86 in × 40.31 in × 50.47 in (784 × 1,024 × 1,282 mm)
• Empty weight: 705 lb (320 kg); Full weight: 1,471 lb (667 kg)
• Maximum hose length: 16 ft (5 m)
• Lifting: 4 x galvanized lifting eyes and forklift pockets; tank can be lifted full
