Aircraft de-icing vehicle GS700 series
sprayer

aircraft de-icing vehicle
aircraft de-icing vehicle
aircraft de-icing vehicle
aircraft de-icing vehicle
aircraft de-icing vehicle
aircraft de-icing vehicle
aircraft de-icing vehicle
aircraft de-icing vehicle
Add to favorites
Compare this product


Characteristics

Applications
for aircraft
Type
sprayer
Tank capacity

200 m³, 600 m³
(7,062.93 ft³)

Description

Dedicated Custom Chassis 800, & 1400 Gallon Capacity (Type I & IV) Mini-Max “Quick Heat System” 980,000 BTU 12V Joystick Controls Single Diesel Engine (Swing out Module) De-Icing Fluid Pump Myers I2C-20 Fluid Delivery (De-Ice) Hardi Rotary Pump 363 Anti-icing Fluid Pump 20-30GPM(76-114L) / 150 psi Fluid Delivery (Anti-Ice) 20 GPM (76L) / 40 psi Heater: GSS “Mini-Max” 12 VDC. 980,000 BTU Quick Heat System Pre-Heat to Deice Time Approx 12 min. Chassis: Custom to Spec. Drive System Hydrostatic / Dynamic Braking Engine Perkins 404D Diesel Fuel Diesel / 50 gal. (189 L) Maximum Speed 20 mph (32km/hr) Max Deicing Speed 3 mph (5km/hr) Aerial Device: Articulating Boom Length 23 Ft. 4 In. (7.1 m) Width 7 Ft. 4 In. (2.2 m) Wheelbase 9 Ft. 3 In.(2.8 m) Height (Boom Retracted) 9 Ft. 7 In. (2.9 m) GVW Empty Tanks 9600 lbs. (4355 kg) GVW Full Tanks 15,800 lbs. (7167 kg)Cal Safety Features Emergency stops in cab and basket. Emergency hydraulic pump control in basket and ground control station. Boom control in basket and ground control station. High Speed Cutout When Boom is Raised. Driver/Passenger seat belts. Caterpillar 2.2 Diesel Cummins 3.3 Diesel Hardi 363 De-Icing Fluid Pump Type IV fill system In Cab Flow Meters Fire extinguisher mounted on unit Full body safety harnesses Dual Heater Option Frost Gun Remote Tank Level Gauges
