Working lifting platform EC600SJ
telescopicsingle-mastfor airport

working lifting platform
working lifting platform
working lifting platform
Add to favorites
Compare this product


Characteristics

Function
working
Technology
telescopic, single-mast
Applications
for airport, for aircraft
Carrying capacity

230 kg
(507.1 lb)

Height

18.4 m, 20.4 m
(60'04" , 66'11" )

Description

Working Outreach: 13.84 m / 45.4 ft Key Features Largest electric drive booms in the industry, offering 20.00 m working heights Increased accessibility with the optional JibPLUS® with side-to-side movement and near-vertical jib operation Zero emissions, reduced noise and standard non-marking tires for environmentally-friendly equipment Standard Automatic Traction Control and oscillating axle for increased manoeuvrability and outstanding terrain performance High-efficiency direct electric drive with longer duty cycles for increased productivity Power Source Batteries - 8 x 6V, 415 A-h Electrical System - 48 Volts DC Performance Data Drive Speed - Platform Lowered - 4.80 km/h / 3 mph Gradeability - 2WD - 30 % Gradeability - 4WD - 45 % Swing - 400 Degrees Swing Type - Non-Continuous Turning Radius - Outside - 4.64 m / 15.2 ft Jib - Range of articulation - 145 Degrees Dimensional Data Ground Clearance - 0.3 m / 1 ft Machine Height - 2.54 m / 8.3 ft Machine Length - 9.37 m / 30.7 ft Machine Width - 2.42 m / 7.9 ft Platform Dimension A - 0.76 m / 2.5 ft Platform Dimension B - 1.83 m / 6 ft Tailswing - 1.23 m / 4 ft Largest electric drive booms in the industry, offering 20.00 m working heights Increased accessibility with the optional JibPLUS® with side-to-side movement and near-vertical jib operation Zero emissions, reduced noise and standard non-marking tires for environmentally-friendly equipment Standard Automatic Traction Control and oscillating axle for increased manoeuvrability and outstanding terrain performance High-efficiency direct electric drive with longer duty cycles for increased productivity
