Measurement software Zenith

CADfor aeronautics3D

Zenith focuses on the essential functions used in most applications for acquisition and 3D measurement of industrial parts. Simple to learn, and free*, but able to manage dense point clouds and color mapping, this is Zenith. Fast point cloud acquisition Manage large point clouds without software slow-down. Filter point clouds to reduce files weight. Select and remove quickly unwanted point cloud zones. Color mapping After aligning the scan to the CAD model with a Landmark and a Best-fit alignment, a color mapping can be generated on the point cloud. Extraction from CAD Extract geometrical entities from CAD and compare them to measured data from point cloud . Geometric acquisition Fast creation and calibration of probes Acquisition of geometrical entities Direct measurement of CAD entities by probing Alignment by 3 geometrical entities or with “plane, line, point” Possible exportation of measured entities in IGES format. Automatic report generation 1 – Specify entities and properties visibility 2 – Organize the tree view to define the report tables order 3 – Generate the report and export it as PDF or CSV.
