Airport control cabinet 48V-NAV-CTR-RI-48-IOT

switching

Product description

• Weather-tight enclosure in stainless steel 316L for outdoor installation
• Outputs for 1 to 4 NAVILITE-IR-48V-CABLE units
• Synchronization of infrared LEDs for coordinated operation
• Continuous power supply for red LEDs
• Test button to bypass photocell and force daytime operation
• Alarm output for fault monitoring
• Master/slave configuration for synchronization of multiple cabinets
• Type 2 surge protection included
• Optional wireless GPS synchronization (P/N113746) and GSM interface

Electrical properties
Main voltage: 48VDC (-10%; +15%)

Mechanical properties
IP rating: IP65 in vertical position
Operating temperature: -20°C to +45°C
Acceptable wire cross section: 1 to 4 mm²

Characteristics / Technical specifications

• Enclosure material: weather-tight stainless steel 316L
• Outputs: 1 to 4 NAVILITE-IR-48V-CABLE
• Infrared LED synchronization
• Continuous red LED power supply
• Photocell bypass test button (forces daytime switching)
• Alarm functionality for monitoring and integration
• Master/slave mode for multi-cabinet synchronization
• Type 2 surge protection included
• Optional: wireless GPS synchronization (P/N113746)
• Optional: GSM interface
• Main voltage tolerance: 48VDC (-10%; +15%)
• IP rating: IP65 (vertical position)
• Operating temperature range: -20°C to +45°C
• Recommended wire cross section: 1 to 4 mm²
