Centrifugal separator SMHF series

The Facet SMHF Series delivers superior water barrier protection as the second stage in coalescer-separator systems for mission-critical aviation fueling applications. Key Features • Qualified to EI 1581 (7th Edition) for Category M, Type S-LW applications in horizontal configurations when combined with Facet CMHF coalescer cartridges in Facet coalescer-separator housings • Hydrophobic barrier blocks residual water droplets after the coalescer stage, preventing water from going downstream • Cleanable and reusable design reduces operational costs and maintenance waste • Synthetic mesh-coated screen enhances water repellency and supports consistent separation efficiency under varying flow conditions Specifications • Max Operating Temperature: 240 ºF (115 ºC) • Max Differential Pressure: 75 psid (5.17 bar) • pH Range: 5 to 9 • Flow Direction: Outside to In • All Materials of Construction are Compatible with EI 1589
