Pressure test chamber EWQT series

temperaturehumidityaeronautical

Altitude Simulation: Sea level to 43,000m (110-0.1 kPa) Rapid decompression: Achieve 16,800m pressure differential (2,500m → 12,500m) within 15 seconds Humidity Range: 10% to 98% RH Noise test：≤ 75dB 2 - Dimension - Internal Dimension WxHxD (mm) - 500x500x500 - 800x800x800 - 1000x1000x800 - 1000x1000x1000 - 1800x1000x1200 - 1730x1980x2600 External Dimension WxHxD (mm) - 900x1680x1750 - 1200x1880x2050 - 1400x2080x2050 - 1400x2180x2250 - 2200x2180x2570 - 2130x2440x4673 2 - Pressure - Pressure range - Normal pressure~0.5Kpa ( 500pa） Pressure error - ≦±2kpa Ordinary pressure ~ 40kpa ≦±5kPa (40kPa to 4kPa) ≦±0.1kpa (4kPa to 1kPa ) Depressurization time - From site level to 15250m in 10min From site level to 22860m in 20min From site level to 30500m in 30min Rapid decompression time - 75.2kPa~18.8kPa≦15s (Optional) Explosive decompression time - 75.2kPa~18.8kPa≦0.1s (Optional) Temperature fluctuation - ±0.5℃ Temperature uniformity - ≦±2.0℃(Normal pressure, no load, constant state) 4 - Heating rate - 2℃/min - 2℃/min - 2℃/min - 2℃/min - 2℃/min - 2℃/min 5 - Cooling rate - 3℃/min - 3℃/min - 1 ~ 3℃/min - 1 ~ 3℃/min - 1 ~ 3℃/min - 1 ~ 3℃/min 6 - Heating - Noise Level Heating/Cooling - 49 - 49 - 49 - 49 - 49 - 49 Cooling - 65 - 65 - 68 - 68 - 66 - 69 7 - Humidity - Humidity range - 10%RH ~98% RH Humidity uniformity - ±1.0% RH Relative humidity deviation - ≦±2.0 to 3.0% RH (humidity >75%RH) ≦±5.0% RH (humidity≦75%RH) 8 - Viewing window size W×H( mm) - 305 × 305 9 - Heating - Noise, heating/cooling - 49 Cooling - 65 - 68 - 69 10 - Rated current ( A ) - 14 - 26 - 34 - 34 - 38 - 114 11 - Rated power ( KW ) - 8.5 - 14 - 20 - 20 - 23 - 48 12 - Power - AC380V 3phase 5lines 50/60Hz 13 - Aprroximate weight(kg) - 850 - 1500 - 1900 - 2000 - 3500 - 9520
