TRELLEBORG elastomeric seals

Temperature limit: -60 °C - 200 °C
Pressure limit: 100 MPa
Diameter: 0.5 mm

... are available on request. In addition, special O-Rings can be supplied with their flashline in a specified position on the seal or inspected to stringent criteria, if required.

Temperature limit: -60 °C - 200 °C
Pressure limit: 200 MPa
Diameter: 0.5 mm

Back-up Rings are commonly used to protect seals from the effects of extrusion when pressurised adjacent to a housing gap. A wide range is available to suit all seals and grooves. Usual configurations ...

Temperature limit: -45 °C - 200 °C
Pressure limit: 35 MPa
Diameter: 4 mm - 2,700 mm

The original seal design developed to improve the performance of the O-Ring and Back-up ring used in the MIL-G-5514F grooves. The Turcon® Double Delta® II is a double-acting sealing element which is energized by an elastomer ...

Temperature limit: -60 °C - 200 °C
Pressure limit: 200 MPa
Diameter: 4 mm - 2,700 mm

... spiralling or rolling under severe working conditions. The small elastomer contact area of the Wedgpak® design, results in a slipper seal type performance, with low static and dynamic friction. At the same time, the elastomer ...

Temperature limit: -40 °C - 200 °C
Pressure limit: 1 MPa
Diameter: 4 mm - 1,800 mm

... within the seal width or beyond the seal base. A successful Radial Oil Seal runs with a thin film of fluid under the sealing lip. The film acts as a lubricant and allows a meniscus to ...

Temperature limit: -30 °C - 200 °C
Pressure limit: 50 MPa
Diameter: 5 mm - 456 mm

... areimportant. Kantseals can be compression molded or machined and additionalcorner chamfers or radii can be used to alter the seal's frictionalbehavior.Available in a full range of elastomer materials compatible withalmost ...

Temperature limit: -150 °C - 200 °C
Pressure limit: 60 MPa
Diameter: 3 mm - 3,300 mm

... load of the helical spring ensures effective sealing even in extremely low temperature applications. These helical spring seals are ideal for slow moving and static applications or in a vacuum sealing applications.The ...

Temperature limit: -30 °C - 200 °C
Pressure limit: 100 MPa
Diameter: 2.5 mm - 125 mm

... bursting forces and limits the deformation of the elastomeric element. This prevents over-compression and extrusion.The standard type Bonded Seal is supplemented by a range of self-centering Bonded Seals ...

Temperature limit: -50 °C - 325 °C

... components, acting as pressure seals, as well as being barriers for fire containment. Fire seals are elastomeric, with glass or ceramic reinforcement. They are commonly tested to ISO ...
