Omnidirectional approach light IWT.852.HEL.01

landingfor heliport useLED

Product overview
Inset Heliport TLOF Light is an inset lighting unit designed for the touchdown and lift-off area (TLOF) of heliports. The lamp is omnidirectional and emits a steady green light. It has a 6.35 mm mechanical protrusion above ground and is fitted with a pressure valve for water-tightness testing. Elevated variants are ICAO-compliant where applicable.

Identification

• Article number: IWT.852.HEL.01 (Green)
• Description: Inset TLOF Light for heliports

Electrical & photometric data

• Power consumption: 7 VA
• Light intensity: Green: 30 cd (omnidirectional, steady)
• Power supply options: 110/230 VAC or 24 VDC (6.6 A SC)
• Operating mode: Steady light

Basic facts

• Light source: LED
• Operating temperature range: -40° to 55°C
• Ingress protection: IP67
• Mechanical protrusion above ground: 6.35 mm
• Dimensions (W x D x H): 203.2 x 203.2 x 90 mm
• Weight: 2.40 kg

Technical specifications

• Product name: Inset Heliport TLOF Light
• Application: Inset light for TLOF (touchdown and lift-off area) on heliports
• Article number / reference: IWT.852.HEL.01 (Green)
• Light colour / output: Green, omnidirectional, steady light, 30 cd
• Power consumption: 7 VA
• Power supply options: 110/230 VAC or 24 VDC (6.6 A SC)
• Light source type: LED
• Operating temperature range: -40° to 55°C
• Ingress protection: IP67
• Mechanical protrusion above ground: 6.35 mm
• Sealing: Fitted with a pressure valve for water tightness testing
• Dimensions (W x D x H): 203.2 x 203.2 x 90 mm
• Weight: 2.40 kg
• Certification / standards: ICAO compliance noted for elevated variant; meets international heliport recommendations where applicable
