3-axis machining center HPX63
horizontalfor the aerospace industry

3-axis machining center
3-axis machining center
Add to favorites
Compare this product


Characteristics

Number of axes
3-axis
Spindle orientation
horizontal
Other characteristics
for the aerospace industry
Rotational speed

Min.: 15 rpm
(94 rad.min-1)

Max.: 6,000 rpm
(37,699 rad.min-1)

X travel

1,000 mm
(39 in)

Y travel

800 mm
(31 in)

Z travel

900 mm
(35 in)

Description

●Box guide ways realize long term high-precision and high rigidity. Heat treated box guide ways are attached to the surface which has high straightness and perpendicularity by scraping.                 ●The load to the column sliding section is reduced by air support for smooth high-speed feed despite the sliding method type ways.        ●Highly rigid Y-shaped integrated three-point support bed is adopted.●Ball screws of all linear axes are placed in the center of the sliding surface to minimize the position difference. (In the case of standard spindle of of HU63A/HU80A)      ●Y axis ball screw is adopted twin drive, minimized position difference. (In the case of HPX63)
