Industrial drone Skylle 2

mappingfixed-wingelectric motor

The Skylle II adopts the aviation carbon fiber unibody molding process, which can cope with the harsh operating environment; quick détachable arm and kickstand design, featuring rapid deployment and portability; integrated modular main board avionics, multiple modular interfaces, compatible with a variety of peripheral interfaces, which can be equipped with auxiliary flight peripherals, such as 4G \5G, RTK, dual-channel mapping, onboard computer, etc., and support the subséquent introduction of upgraded accessories to carry out a seamless itérative upgrading; Multi-mount interface, can be matched with our standardized payload, to meet most of the industry application requirements; dual backup intelligent battery design, bringing a safer flight experience. Material: carbon fiber, magnesium aluminum alloy, engineering plastics Wheelbases: 1650mm Packing Dimension: (Fuselage) 820*750*590mm (Arm) 1090*450*350mm Unfold max. dimension: 1769*1765*560mm (Without paddle) Unfold max. dimension: 2190*2415*560mm (With paddle) Body weight: 9.15kg (Without battery and mount) Unladen weight: 18.2kg Endurance: 80min@no load; 60min@1kg;55min@3kg 48min@5kg; 40min@8kg; 36min@10kg; Automatic obstacle avoidance function: 360° omnidirectional obstacle avoidance (horizontal) Max. wind résistance: 12m/s (Class 6) Frequency of image transmission: 2.4GHz Encryption method: AES256 Mapping distance: 20km Operatingtempérature: -20°C~60°C Operating humidity: 10%~90% non-condensing Protection level: IP54 Electromagnetic interférence: 100A/m (industrial frequency magnetic field) Cruising speed: 0~15m/s Max. flight speed: 18m/s Max. climb speed: default 3m/s (max. 5m/s)
