Towed PCA unit D120R
electricfor aircraft

towed PCA unit
towed PCA unit
Add to favorites
Compare this product


Characteristics

Mobility
towed
Other characteristics
electric
Applications
for aircraft
Cooling power

23 kW

Heating power

120 kW

Air flow

Max.: 6,200 m³/h (218,950.934 ft³/h)

Min.: 0 m³/h (0 ft³/h)

Description

NORDIC HEATER D120R TECHNICAL DATA Power package Deutz diesel, 2 cylinders with integrated oil-cooling. 23 kW. Burner Bentone 120 kW / 400,000 BTU. Patent pending high performance electric fan unit with two fan speeds. Max flow 6200 m³/h / 3649 CFM. Max pressure 3.5 kPa / 0,51 PSI. Temperature + 10ºC / 50ºF – + 115ºC / 239ºF. with presets + 30ºC / 86ºF and + 60ºC / 140ºF. ​The heater is equipped with a tow bar which activates the brakes on the front wheels. OPTIONS Hose longer than std 7,5 meters / 295 inch. Beacon light. Spare parts kit. GPS positioning system. Optional colors and logos MORE DETAILS 13 inch pneumatic, reinforced tires. Front-wheel driven with a narrow wheel set and rigid rear axle. Service hatches with gas cylinders. Chassis, frame, roof and hatches made of stainless steel. New and highly efficient heating fan for fuel savings. Clean and open design allowing for easy access for service on all parts. 7,5 m long / 295 inch PVC coated, 203 mm / 7,99 inch diameter, heater air hose with very resistant PCA connection to aircraft as standard. Patented PCA connection to the cabin, made of nylon with a neoprene seal. The connection is UV resistant and resistant to chemicals and fuel. New high-efficiency burner for fuel savings. Stainless steel heat exchanger. 1,000-hour service intervals. Fuel capacity 200 litres / 53 gallons. ​Operation time 48 hours DIMENSIONS Length 2360 mm 93 inch Width 1400 mm 55 inch Height 1525 mm 60 inch Weight 1085 kg 2392 lbs Fuel 200 liters 53 gallon
