thermosetting resin / for composites
EX-1510

Add to MyAeroExpo favorites
Compare this product Don’t compare this product
thermosetting resin thermosetting resin - EX-1510
{{requestButtons}}

Characteristics

  • Other characteristics:

    thermosetting

  • Other characteristics:

    for composites

Description

Product description
EX-1510 is a highly modified two-part toughened cyanate ester resin formulated to have extremely low viscosity at room temperature. Its viscosity allows resin transfer molding (RTM) to take place without the application of heat to the resin. This feature provides long resin pot life and mold filling time for difficult and/or large RTM’d structures and helps increase manufacturing efficiency and reduces waste.

EX-1510 displays excellent mechanical and thermal properties in addition to low moisture absorption. Finally, the material is unique in that it develops full mechanical properties from its initial 177°C (350°F) cure. A freestanding post cure increases the heat resistance.

Product benefits/features
Low viscosity at room temperature of 150 cPs
Postcurable

Market segments
High Temperature
Space & Satellite
Aerostructures

Details
Product categoryRTM resins
ProcessingPress forming
Post curable
Resin typeCyanate Ester
Tg (Dry, onset)193 °C / 379 °F
Cure temperature (Optimal)177 °C / 350 °F
Cure temperature (Lowest)177 °C / 350 °F
Cure temperature (Highest)177 °C / 350 °F
Out life4 hours
Post curable
