Stairs

Height range: 2,450 mm - 5,750 mm

Min. – max service heights 2450 - 5750 mm Passenger capacity 50 persons Steel construction, white color painted acrylic carriage chassis. Electrical controlled hydraulic valves Hand pump for emergency hydraulic ...

Maximum Loading per step 2 person / 160 kg Maximum Loading of front platform 3 person /240 kg Aluminum Step Size 300x1200mm Type 4 solid rubber tires 4.00-8 Brake system acting on front wheels when tow bar is up-rised ...

Height range: 2 m - 3.7 m

Adjust service 2.00-3.70 M Maximum Loading per step 2 person / 160 kg Aluminum Step Size 300 x 1200 mm Maximum Loading of front platform 6 person /450 kg Aluminum platform 1600 x 2000 mm Type 4 solid rubber tires ...

Height range: 2,400 mm - 5,800 mm

... Speed:30 km / hELECTRICAL SYSTEM:12 V DC (24 V Optional)OPTIONAL ITEMSCanopy:The stair and platform group is covered with fixed canopy.Canopy & Folding Bellows:The stair is equipped with a folding ...

Height range: 2,400 mm - 5,800 mm

Passenger Stair over Truck MS-5800Product SpecificationsThe passenger stair is constructed in conformity with AHM, VDE and IATA standarts.SERVICE RANGE OF PASSENGER STAIRStair working on telescopic principle ...

Height range: 2,400 mm - 5,800 mm

The passenger stair is constructed in conformity with AHM, VDE and IATA standarts.SERVICE RANGE OF PASSENGER STAIRStair working on telescopic principle aided with tilt cylinder.Service Range:2400 - 5800 mmOVERALL DIMENSIONS ...

Height range: 1.4 m - 2.9 m

SKY MASTER PASSENGER STEPS PS5-9 The PS5-9, the smallest Towable Passenger Stair unit in the range Height range: 1400-2900mm Max. Passengers capacity: 20 pax Typical Options: Diesel/electric motor-pump (lifting and ...

Height range: 1.77 m - 4 m

SKY MASTER PASSENGER STEPS PS6-13 The PS6-13 Towable Passenger Stair allows passenger access to small and medium sized aircraft. Height range: 1770-4000mm Max. Passengers capacity: 25 pax Typical Options: Diesel/electric ...

Height range: 2.01 m - 4.42 m

SKY MASTER PASSENGER STEPS PS7-15 The PS7-15 Towable Passenger Stair allows passenger access to small and medium sized aircraft. Height range: 2010-4420mm Max. Passengers capacity: 27 pax Typical Options: Diesel moto-pump ...

maintenance stairs: fix or height adjustment, use of aluminium alloy,hydraulic control system, conduct to lightness, easy handling and safety. Platform shape and height are adjustable for all type of maintennace activity.

Height range: 2.41 m - 3.31 m

OT-14 STAIRS Suitable for Crew Max. platform length5364 mm Max. platform width2768 mm Tara weight 1515 kg

Height range: 3.75 m - 5.18 m

OT-22 STAIRS Suitable for Crew Max. platform length7677 mm Max. platform width2768 mm Tara weight 2366 kg

Height range: 1.85 m - 3.2 m

PT-15 STAIRS Suitable forPassengers Max. platform length6587 mm Max. platform width1800 mm Tara weight1405 kg

Universal, fixed-height maintenance steps ZARGES universal, fixed-height maintenance stairs can be used on a multitude of aircraft types Short set-up times keep downtimes to a minimum. They are easy to manoeuvre both ...

JBT self-propelled and towed passenger boarding steps are available in diesel and all-electric designs to service aircraft ranging from large regional jets up to the A380 main deck. HIGHLY RELIABLE Four stabilizers located at the ...

Height range: 8.3 m

Airfield operation of the highest level The escape stair is a specially developed operational vehicle for rapid evacuation of aircraft passengers. At the same time, operational forces like firefighters, rescue and emergency ...

Height range: 2.4, 3.8 m

Independent stairs of new design, with electric drive and additional option of solar panels. All functions of these passenger stairs are carried out exclusively by electrical systems and elements, while ...

Height range: 2.52 m

The TBD Owen Holland TPS26 offers a stylish low cost solution for single aircraft fleet B737 operations. Lightweight yet robust construction saves time and effort when manually maneuvering the steps to and from the aircraft. The TPS26 ...

Height range: 3.7 m - 7.5 m

Truck mounted stair The Universal Maintenance Stair is a self-propelled maintenance equipment. Applicable to all Narrow and Wide Body Aircraft. Height adjustable from 3700 mm to 7500 mm. The Truck ...

Height range: 1.7 m - 4 m

The ABS-1740 Aircraft Passenger Boarding Stair is designed for servicing aircraft with doorsill heights between 1.7m and 4.0m. Stair assembly is mounted on a self-propelled chassis with diesel engine ...

WGKT44,WGKT54,sériés passenger steps Vehicles are designed to embark/disembark passengers to/from aircraft.

Height range: 3.25 m - 5.8 m

The telescopic passenger stair is a tow-version with accessory drive for single operator control. It is designed to ensure a comfortable, fast and safe operation on the apron. The platform height from 3.250mm to 5.800mm ...

Height range: 1.97 m - 4.3 m

... Narrow Body Aircraft Passenger Stair Model 170 services doorsill heights from 77.5" up to 170.5" (4.3 m) and meets SAE ARP 836 and 1247. A tubular wrap-around steel bumper deflects ramp impacts—helps protect both the ...

Height range: 1 m - 1.6 m

... powered version is now available. The Aviramp Lite is a simple, yet revolutionary boarding ramp, which eliminates the use of stairs and other costlier GSE and PRM equipment. This model is a portable boarding ramp, designed ...

Height range: 2,200 mm - 5,800 mm

This telescopic passenger stairs is designed to manage passengers disembarking of the aircrafts doors ; located at a height between 2200 to 5800 mm. This model is equipped with a PLC control which handles not only the ...

... size and weight stairs which can not be moved by one person alone are fitted with an auxiliary drive. The drive can be based on either a diesel or an electric motor. These stairs too are manufactured ...

Technical Specifications The Mallaghan ® Autonomous ‘self-docking ‘ Passenger Stair. ADVANTAGES • Reduces damage to aircraft • Speeds up turnaround times for aircraft • Provides Green technology CHARACTERISTICS • Self-propelled • ...

Height range: 2,400 mm - 4,400 mm

... Dimension(LxWxH):8480mm*2100mmx3420mm Diesel Engine:ISUZU 4HK1-TC Manual Transmission Step Size(LxW):300mm* 1400mm Number of stairs:22 Curb Weight4600kg Platform Dimension(LxW):2150mmx1700mm Platform height range:2400-4400mm Passenger ...

Height range: 4,445, 3,760 mm

Additionally, EAGLE Industries has a collaboration agreement with S-P-S to produce a wide range of non-motorized Airport Ground Support Equipment (GSE) such as dollies, baggage carts, passenger and maintenance steps. ​ We also manufacture ...

Height range: 2.3 m - 4.4 m

... benefits are: Parallelogram stair section ensuring level stair treads at all positions Electronic automatic transmission ensuring no degradation of performance as can be experienced with hydrostatic ...
