Metal cutting machine KASTOverto A 2

discfor aeronautics

KASTOverto A 2 Fully Hydraulic High Performance Straight Cut Band Sawing Machine with vertically running and horizontally movable saw blade for mass production, cuts of easy to difficult materials, in solids, tubes and profiles. Total machine enclosure according to the machinery directive 2006/42/CE Hydraulic blade tensioning Double clamping vice system: Work piece clamping on both sides of the saw blade Linear guides on saw head, material feed and clamping vice systems Hydraulic blade side shift cylinder for contact-free return of blade from kerf. Technical dataKASTOverto A 2 Cutting range Form Cutting range 320 x 260 mm / 260 x 260 mm / 260 mm Smallest cut-off length 10 mm Shortest length of residual piece, single cut 15 mm Shortest length of residual piece, automatic operation 40 mm Shortest length of cut-off piece 6 mm Length 2.365 mm Width with chip conveyor approx. 2.250 mm Width without chip conveyor approx. 1.350 mm Height 1.767 mm Total weight 1.260 kg Material support height 950 mm Performance characteristics Connected load 2,5 kW Saw motor, frequency controlled 1,5 kW Cutting speed infinitely variable 12 - 120 m/min Material feed length - individual feed 850 mm Multiple feed 9.999 mm Dimensions of saw blade 3.180 x 27 x 0,9 mm Cutting feed hydraulically adjustable 0 – 300 mm/min Material feed ball screw spindle Material clamping hydraulic Saw blade cleaning by means of interchangeable wire brush, driven proportionally to main drive
