Aerial photography camera X2C

ruggedizedfor dronesstabilized

Overview
MMC X2C is a five-lens oblique aerial survey camera engineered for high-precision 3D modeling, capturing vertical and multi-angle oblique images simultaneously to deliver rich terrain texture and accurate reconstructions. It targets demanding surveying, mapping, construction, public-safety and geospatial workflows that require high resolution, fast data handling and rugged field reliability.

Core advantages

• Multi-angle capture: simultaneous vertical + 45° oblique images from five lenses to eliminate blind spots and provide full spatial texture for 3D reconstruction.
• Multi-platform compatibility: wide voltage input (12–50 V) and detachable gimbal design for straightforward integration with diverse UAV platforms (example integration: Skylle II).
• Efficient data workflow: hot-swappable storage modules and Type‑C high-speed transfer (≥300M/s) plus real-time POS embedding in images to accelerate survey turnaround.
• Precision imaging: 125 MP total system resolution (≈25.16 MP per lens) with global shutter (S-GS) and five-phase closed-loop detection to ensure sharp, distortion-free multi-angle datasets.
• Rugged field reliability: industrial-grade metal/composite construction, cable-free exterior and smart thermal control with operating range −20°C to 65°C for extreme-field use.

Applications & workflow highlights

• Topographic surveying, cadastral mapping and architectural 3D reconstruction: captures high-detail terrain texture and structure for photogrammetric outputs.
• Engineering & construction monitoring: supports close-range photogrammetry (millimeter-level detail) and flexible use of a single nadir lens (25 mm) or full five-lens mode for complex scenes.
• Public-sector and geospatial projects: motion-robust imaging (global shutter), on-board POS integration and KML/GIS-friendly outputs streamline large-scale infrastructure mapping and risk assessment.

Technical specifications

• Total resolution: 125 MP (approx. 25.16 MP per lens).
• Sensor format: APS-C (23.1 mm × 15.4 mm).
• Pixel size: 3.76 μm.
• Shutter: S-GS global shutter (motion-blur elimination at speed).
• Lenses: five-lens configuration — nadir (25 mm) + four oblique (45°) to provide vertical + multi-oblique coverage.
• POS / geotagging: five independent, real-time POS datasets embedded directly into photos for high-accuracy georeferencing.
• Data storage: hot-swappable storage modules (example capacity referenced: 1280 GB modules).
• Data interface: Type‑C high-speed transfer ≥300M/s; supports hot-swap offload without powering camera on.
• Power input: wide input range 12–50 V (multi-platform compatibility).
• Operating temperature: −20°C to 65°C; smart thermal control.
• Build: industrial-grade metal/composite with CNC aluminum elements; cable-free exterior for field robustness.
• Stabilization / gimbal: detachable gimbal design; three-axis stabilized gimbal referenced for platform integration.
• Detection & control: five‑phase closed-loop detection; support for Bluetooth parameter adjustment and open interfaces for secondary development.
• Workflow / software: real-time POS embedding, KML/GIS integration-friendly outputs and firmware/mission management support for survey software integration.
• Primary use cases: professional surveying & mapping firms, engineering & construction teams, government/public utilities, geospatial/AR/VR innovators.
