Baggage scanner SA6550D

for parcelfor cargoinspection

Securina SA6550D Dual View x-ray baggage inspection system can display horizontal and vertical images by two independent generators, which can identify overlapping articles and contraband easily and precisely. Securina SA6550D is a middle capacity X-Ray scanning unit designed for processing higher quantities of packages or baggages in Goods In and mailroom settings. The dual X-ray generator security inspection X-ray baggage scanner machine with multi-energy X-ray scanner delivers a clear picture of hidden explosives, weapons, drugs, and other contraband in hand-carried and small to mid-sized items. This dual-view x-ray scanner displays two separate, perpendicular X-ray images to provide a complete inspection in a single scan. Applications: - Cargo Screening - Passenger, Staff & Visitor Checkpoint Inspection - Corporate, Government & Private Security - Critical Infrastructure Security - Mail Screening General specifications: - Tunnel size: 650mm*500mm (W*H) - Conveyor speed: 0.22m/s - Conveyor height: 669mm - Maximum load: 160kgs (evenly distributed) - Wire resolution: 40AWG (dia 0.0787mm wire) - Spatial resolution: Level: dia1.0mm copper wire, Vertical: dia1.0mm copper wire - Penetration (steel): 30mm guarantee, 32mm typical - Penetration resolution: 32AWG (0.202mm) - Display: 17inch (19inch optional) color LCD monitor, high resolution: 1280*1024 - X Ray generator anode voltage: 140-160Kv - Cooling cycle: Oil Cooling /100% - X ray dose per inspection: <1.0 μSv - X ray generator: 2 - Beam direction: top/side - Image process: Black and white / color, anti-color, high energy penetration, super enhancement, histogram equalization, forced scanning, magnifying glass, image pull back / front pull, image storage - Material classification: Organic: orange; Inorganic: blue; Mixed and light metal: green - Section and magnification: Any area selection, 1-64 times magnification, support continuous amplification - Image pull back: Can pull back 50 images - Storage capacity: Can store at least 100000 pcs image - X ray leakage: <0.5 μSv /h (at a distance of 5cm from external housing), meets all international and domestic health and safety standards - Film safety: guarantee ASA/ISO1600 Film - Software system: F1, F2, F3 programmable key, high density alarm, TIP; date/time display, baggage count, user management, system work timing, radiation timing, self-inspection while power on, save and search image, automatic maintenance and diagnosis system, image recognition training. - Optional function: Video surveillance system, LED prompt screen, bi-direction scan, voltage stabilizer, UPS back up - Physical size: 2456*1348*1331mm (L*W*H) - Weight: 750kgs - Operation temperature/Humidity: 0ºC~+40ºC+/-2ºC; 5%~95% (non-condensing) - Storage Temperature/Humidity: -20ºC~+60ºC+/-2ºC; 5%~95% (non-condensing) - Operation power: 220VAC (+/-10%) 50+/-3HZ - Power consumption: 1.0KvA - Noise: Less than 60db - Product Item: SA6550D - Tunnel size: 650(W)*5000(L)mm - Double x-ray generators: Dual-view scanning image - Tube Voltage: 140-160KV - Warranty: 1 year Tags: x-ray explosive detector, x-ray screening security system, dual-view x ray scanner, dual-view cargo scanner machine, dual-view security x-ray equipment - Operation training program for end users - Free of factory training for engineer from agents to end user - Provide on-site training when customer requires - If quality problems happen in guarantee period, company will maintain for free - One year free spare parts and lifetime technical support - After-sales service isn't restricted by time and technical personnel will solve problems immediately after receiving feedback Technical Specifications / Features: - Dual-view X-ray imaging (horizontal and vertical) - Multi-energy X-ray scanner - High penetration and resolution - Large storage capacity (100,000+ images) - Programmable software system with alarms and diagnostics - Optional video surveillance and UPS backup - Meets international health and safety standards
