Baggage scanner SA10080

inspectionfor airportX-ray

Securina SA10080 X-ray security inspection equipment is composed of the baggage handling system, X-ray source and control unit, signal acquisition and processing unit, transmission unit, image processing unit, and electric control unit.Working flow:Securina SA10080 X-ray security inspection equipment sends checked baggage into the crawler channel for transfer via the conveyor belt.1. Goods enter the channel, detection device and relevant information are sent to the control unit, and the X-ray source emits X-rays triggered by the control unit.2. X-rays pass through the collimator forming a very narrow fan beam, which passes through the conveyor belt and into the luggage on the detector. The X-ray detector converts received X-rays into electrical signals.3. The weak current signal is amplified and quantified, transmitted via USB to the industrial control computer for further processing, and after complex imaging processing, high-quality images are obtained.Application field: Train Stations; Metro Stations; Jail Houses; Embassies; Border check points; Entertainment venues; Tourist attractions; Office buildings; Shopping malls; Factories, etc.*Suitable for security inspection of briefcases, hand luggage, postal parcels, and other small packages.General specifications:Tunnel size1000mm*800mm (W*H)Conveyor speed0.20m/sConveyor height338.5mmMaximum load200kgs (evenly distributed)Wire resolution40AWG (dia 0.0787mm wire)Spatial resolutionLevel: dia1.0mm copper wire, Vertical: dia1.0mm copper wirePenetration (steel)30mm guarantee, 32mm typicalPenetration resolution32AWG (0.202mm)Display17 inch (19 inch optional) color LCD monitor, high resolution: 1280*1024X Ray generator anode voltage140-160KV adjustableCooling cycleOil Cooling / 100%X ray dose per inspection<1.0 μSvX ray generator1Beam directionfrom top to bottomImage processBlack and white / color, anti-color, high energy penetration, super enhancement, histogram equalization, forced scanning, magnifying glass, image pull back / front pull, image storageMaterial classificationOrganic: orange; Inorganic: blue; Mixed and light metal: greenSection and magnificationAny area selection, 1-64 times magnification, support continuous amplificationImage pull backunlimited imagesStorage capacityCan store at least 100,000 imagesX ray leakage<0.5 μSv/h (at a distance of 5cm from external housing), meets all international and domestic health and safety standardsFilm safetyguarantee ASA/ISO1600 FilmSoftware systemF1, F2, F3 programmable key, high density alarm, TIP; date/time display, baggage count, user management, system work timing, radiation timing, self-inspection while power on, save and search image, automatic maintenance and diagnosis system, image recognition training.Optional functionVideo surveillance system, LED prompt screen, bi-direction scan, voltage stabilizer, UPS backupPhysical size3638.5*1295*1916mm (L*W*H)Weight1370kgsOperation temperature/Humidity0ºC~+40ºC; 5%~95% (non-condensing)Storage Temperature/Humidity-40ºC~+60ºC; 5%~95% (non-condensing)Operation power220VAC (+/-10%) 50+/-3HZPower consumption1.0KvANoiseLess than 55dbOperation training program for end usersFree factory training for engineers from agents to end usersOn-site training available upon customer requestFree maintenance for quality problems during warranty periodOne year free spare parts and lifetime technical supportAfter-sales service not restricted by time; technical personnel assigned to solve problems immediately upon notificationTechnical Specifications / Features:Product Item: SA10080Tunnel size: 1000(W)*800(L)mmMonitors: Two unitsTube Voltage: 140-160KVWarranty: 1 yearCategory: X-ray Security Scanner
