Baggage scanner SA100100D

for airportX-ray

Securina SA100100D Dual-View Security X-ray Luggage Screening Machine is equipped with double x-ray generators. Dual-View provides security screening personnel with the ability to see two views from scanning the object just once, as two views from different angles (usually from the top and the side) are taken as the object passes through the X-Ray security screening device. Large tunnel size: 100cm(W) x 100cm(H). Using a Dual-View X-Ray security screening machine greatly increases efficiency. Legislation for cargo screening within airports is increasingly requiring all cargo to be scanned across two different angles. Using conventional screening technology means users have to screen each item of cargo twice. However, dual view technology allows these two required views to be obtained from just one pass through the machine. Application field: Train Stations; Metro Station; Jail House; Embassy; Border check points; Entertainment venues; Tourist attractions; Office buildings; Shopping malls; Factories, etc. *Suitable for security inspection of briefcase, hand luggage, postal parcels and other small packages. General specifications: - Tunnel size: 1000mm*1000mm (W*H) - Conveyor speed: 0.20m/s - Conveyor height: 310mm - Maximum load: 200kgs (evenly distributed) - Wire resolution: 40AWG (dia 0.0787mm wire) - Spatial resolution: Level: dia1.0mm copper wire, Vertical: dia1.0mm copper wire - Penetration (steel): 30mm guarantee, 32mm typical - Penetration resolution: 32AWG (0.202mm) - Display: 17 inch (19 inch optional) color LCD monitor, high resolution: 1280*1024 - X Ray generator anode voltage: 140-160Kv - Cooling cycle: Oil Cooling / 100% - X ray dose per inspection: <1.0 μSv - X ray generator: 2 - Beam direction: top/side - Image process: Black and white / color, anti-color, high energy penetration, super enhancement, histogram equalization, forced scanning, magnifying glass, image pull back / front pull, image storage - Material classification: Organic: orange; Inorganic: blue; Mixed and light metal: green - Section and magnification: Any area selection, 1-64 times magnification, support continuous amplification - Image pull back: Can pull back 50 images - Storage capacity: Can store at least 100,000 images - X ray leakage: <0.5 μSv/h (at a distance of 5cm from external housing), meets all international and domestic health and safety standards - Film safety: guarantee ASA/ISO1600 Film - Software system: F1, F2, F3 programmable key, high density alarm, TIP; date/time display, baggage count, user management, system work timing, radiation timing, self-inspection while power on, save and search image, automatic maintenance and diagnosis system, image recognition training. - Optional function: Video surveillance system, LED prompt screen, bi-direction scan, voltage stabilizer, UPS backup - Physical size: 3916*1781*1885mm (L*W*H) - Weight: 1450kgs - Operation temperature/Humidity: 0ºC~+40ºC+/-2ºC; 5%~95% (non-condensing) - Storage Temperature/Humidity: -20ºC~+60ºC+/-2ºC; 5%~95% (non-condensing) - Operation power: 220VAC (+/-10%) 50+/-3HZ - Power consumption: 2.0KvA - Noise: Less than 55db - Operation training program for end users - Free factory training for engineers from agents to end users - On-site training available upon customer request - Free maintenance for quality problems during the guarantee period - One year free spare parts and lifetime technical support - After-sales service not restricted by time; technical personnel assigned to solve problems immediately upon notification Technical Specifications / Features: - Dual-view X-ray inspection system - Tunnel size: 1000mm x 1000mm (W x H) - Double x-ray generators - Tube Voltage: 160KV - Warranty: 1 year - Conveyor speed: 0.20m/s - Maximum load: 200kg - Penetration (steel): 30mm guarantee, 32mm typical - Display: 17" (19" optional) color LCD, 1280*1024 resolution - Physical size: 3916*1781*1885mm - Weight: 1450kg - Operation temperature: 0ºC~+40ºC - Power: 220VAC, 2.0KvA
