CNC milling machine NORMAPROFIL T2515
verticalfor aeronautics5-axis or more

CNC milling machine
CNC milling machine
CNC milling machine
CNC milling machine
CNC milling machine
CNC milling machine
CNC milling machine
Add to favorites
Compare this product


Characteristics

Type
CNC
Spindle orientation
vertical
Other characteristics
for aeronautics, 5-axis or more
X travel

3,100 mm
(122 in)

Y travel

2,100 mm
(83 in)

Z travel

870 mm
(34 in)

Description

Fixed table, mobile gantry, 4 cartesian axes, 2 polar axes The complete and versatile NormaProfil T series 5-axis CNC milling machine is optimized for machining large parts produced by thermoforming. TECHNOLOGIES Transmission by ball screw on the 4 Cartesian axes (X1, X2, Y, Z) 2 rotary axes (C: +/- 200 ° and A: +/- 200 ° depending on the electrospindle) Many electrospindles available The NormaProfil T series is optimized for workpiece machining in the following materials: Plastic and composites Synthetic resins PU and PS foam Wood and wood products Aluminum Brass and alloys SOME OF THE POSSIBLE OPTIONS Front and rear automatic doors Movable partition for commuter work (manual or automatic) Vacuum plate for holding parts or tools (vacuum technology by side channel turbines or by vacuum pump) Static tool magazine (6,10,15 tools) Tool measuring probe Sound-absorbing full cover Other useful formats

VIDEO

Catalogs

No catalogs are available for this product.

See all of MECANUMERIC‘s catalogs
