Towing tractor WGQY15

pushbackfor aircraftdiesel

Overview
The Conventional aircraft tow tractor WGQY15 is designed for pushback and towing of small to medium commercial aircraft. It features a compact low-profile chassis, power-shift transmission and a spacious operator cabin. Suitable for gate pushback operations and maintenance towing in airport apron and ramp environments.

Product Description
An aircraft tow tractor is a specialized ground support vehicle used to push back, tow and position aircraft on the apron. The WGQY15 provides controlled tractive effort and maneuverability to safely move aircraft between gates, taxiways and maintenance areas while meeting airport operational procedures.

Key features

• Towing capability: Designed to tow regional to medium commercial aircraft; max towing capacity Low gear 54 kN, High gear 16 kN.
• Versatility: Adaptable to various aircraft types and compatible with standard tow bars and towing attachments.
• Towing mechanism: Tow bar/towing attachment interface for nose landing gear or approved tow points.
• Drive and steering: Full four-wheel drive with differential lock via shaft and front-wheel steering for tight turning radius.
• Powertrain and performance: Diesel engine 73.5 kW @ 2600 rpm; max vehicle speed (full load, without towing) High gear 49 km/h, Low gear 15 km/h; minimum turning radius 4.75 m.

Specification
AIRCRAFT TOW TRACTOR
Diesel Engine - Max. power: 73.5Kw/2600rpm
Overall dimension (length x width x height): 5592×2158×1638mm
Wheel Base: 2050 mm
Wheel Tread: 1702 mm
Overall weight: 7550 KGs
Max. Towing Capacity - High gear: 16kN; Low gear: 54kN
Max. vehicle speed (full load without towing) - High gear: 49km/h; Low gear: 15 km/h
Min. Turning Radius: 4.75m
Front traction coupling / Ground Clearance: 387mm
Rear traction coupling: 519mm
Driving type: Full four wheel driving, Differential Lock with shaft
Steering Type: Front wheel steering

Technical characteristics

• Model: WGQY15
• Brand: CheersMetal
• Code: TT-15
• Diesel Engine Max. power: 73.5Kw/2600rpm
• Overall dimension (L×W×H): 5592×2158×1638mm
• Wheel Base: 2050 mm
• Wheel Tread: 1702 mm
• Overall weight: 7550 KGs
• Max. Towing Capacity (High gear): 16kN
• Max. Towing Capacity (Low gear): 54kN
• Max. vehicle speed (High gear): 49km/h
• Max. vehicle speed (Low gear): 15 km/h
• Min. Turning Radius: 4.75m
• Front traction coupling / Ground Clearance: 387mm
• Rear traction coupling: 519mm
• Driving type: Full four wheel driving, Differential Lock with shaft
• Steering Type: Front wheel steering
