Approach light

PAPIlandingfor airport

Product Description
The Precision Approach Path Indicator (PAPI) is designed for civil airports and heliports to provide pilots with a clear visual glide-path reference for safe approach and landing. The unit integrates electronic angle monitoring, onboard logging and robust environmental protection for reliable field operation.

Specification

• Automatic shutdown when the elevation angle exceeds the preset threshold; each lamp includes an individual electronic angle chip with real-time LED digital readout (accuracy up to 0.01° / 0.6 points) and onboard angle data storage.
• Separate "operation" and "flight-calibration" modes to simplify commissioning and in-field adjustments.
• Individual lamp runtime tracking with system status logging and exportable records.
• Integrated calibration bubble to verify optical angle after flight calibration.
• Control electronics thermally isolated from heat sources to reduce risk of heat-related failures.
• Self-positioning optical design for lamps and color filters, eliminating the need for re‑calibration when replacing optical components.
• Lightweight aluminum-alloy housing with specialized surface treatment; all fasteners in corrosion-resistant stainless steel.
• Compact footprint with aerodynamic design offering wind resistance up to 161 km/h.

Product images available showing front view, cover and internal components for inspection and installation reference.

Features

• Per-lamp electronic angle monitoring with LED digital display and data retention.
• Independent operation and flight-calibration modes for straightforward troubleshooting.
• Runtime and status logging for predictive maintenance planning.
• Built-in calibration bubble to confirm alignment after calibration.
• Thermally isolated control system to enhance reliability in high-temperature conditions.
• Self-positioning optical assembly to speed up lamp/filter replacement without re-calibration.
• Durable construction: aluminum-alloy housing and stainless-steel fasteners for corrosion resistance.
• Engineered for high wind loads (up to 161 km/h).

Technical parameters

• Power: 400 W
• Ambient temperature range: -55 °C to +55 °C
• Protection rating: IP65
• Light intensity: 30,000 cd; transition zone < 3

Why choose us

• Direct manufacturer with production capacity and traceable supply chain.
• Dedicated R&D team for product updates and custom adaptations.
• In-house quality control and testing procedures.
• Experienced export and international logistics support.
• Technical sales team and after-sales service for installation support and spare parts.
• One-stop solution: production, testing, certification support and delivery.

Characteristics / Technical specifications

• Denomination: Precision Approach Path Indicator (PAPI)
• Power: 400 W
• Ambient temperature: -55 °C to +55 °C
• Protection rating: IP65
• Light intensity: 30,000 cd (transition zone < 3)
• Angle measurement accuracy: up to 0.01° displayed on LED digital readout
• Individual electronic angle chip per lamp; angle data storage
• Separate operation and flight-calibration modes
• Runtime logging for each light source
• Built-in calibration bubble for flight-calibration verification
• Thermally isolated control system
• Self-positioning optical design; no re-calibration required after optical replacement
• Housing material: lightweight aluminum alloy with special surface treatment
• Fasteners: stainless steel
• Wind resistance: withstands up to 161 km/h
