STANDARD EQUIPMENT (included)
HKS 700 Powerplant Engine,
warp drive propeller,
EIS - Engine information system,
15" Main gear tires with aluminum wheels and Hydraulic brakes, 13" Nose gear with aluminum wheel,
Steel main wheel axle stubs,
Center mounted controls with brake handle,
Large lord mounted anti-vibration engine mount,
Steel pilot roll cage and nose struts,
Aerodynamic lift ana jury struts with adjustable fittings,
High lift airfoil with 14" rib spacing,
Center hard-shell gap cover,
16 Gal wing Mounted Fuel Cells,
Bungee trim system
GENERAL SPECIFICATIONS
MModelHKS 700
No. Cylinders2
Displacement580 CC
Horsepower58.5 H.P.
Recommended T.B.O.1000 Hrs
PropellerPF ADJ
Length19 ft
Height7 ft 10 in
Wi ngspan30 ft 9 in
Wing Area168 sq. ft
Wing Loading5.95 lb/ft
Seats1
Empty weight425 lbs
Useful Load575 lbs
Payload W/Full Fuel479 lbs
Max Take-off Weight1000 lbs
Fuel Capacity (Standard)16 gal
PERFORMANCE
Takeoff Distance, Ground Roll 125 ft
Takeoff Distance, 50 Ft Obstacle 425 ft
Rate of Climb 825 fpm
Max Level Speed, Sea Level 67 mph
Landing Distance, 50 Ft Obstacle 200 ft
Landing Distance, Ground Roll 55 ft
Minimum sink Rate 475 fpm
Glide Ratio 5.95 : 1
