Rod PPS Meldin® 4000 PAI

aeronautical

Product overview
Meldin® 4000 is Omniseal Solutions' line of PAI (polyamide-imide) based compounds. Individual grades in the 4000 series differ by formulation to provide specific combinations of thermal stability, mechanical strength and wear performance. Meldin® 4000 materials are supplied primarily as injection-molding grades capable of meeting tight dimensional tolerances; limited prototype shapes are also available.

Key properties

• Mechanical strength retained at elevated temperatures
• High fatigue resistance under cyclical stress (preserved tensile and flexural properties)
• Excellent wear resistance and durability in abrasive or harsh environments
• Chemical compatibility with many fluids (e.g., fuels and oils)
• Self-lubricating behaviour and dimensional stability in aggressive chemical environments

Standard specifications (summary)
Materials: Polyamide-imide (PAI) — engineered for low wear under high load
Service conditions: Temperature range: -200°C to +290°C; Typical mechanical strength: 70 MPa
Manufacturing process: Hot compression molding; Injection molding
Features: Tolerance control (injection molded): ±40 μm; Production capacity: >4 M/yr; Defects program target: 0 ppm
Typical dimensions (injection molding): φ = 2–200 mm

Performance highlights / benefits

• Suitable replacement for metal components where stiffness and elevated-temperature strength are required
• Durable under heavy wear and in harsh service conditions
• Formulated for precision injection molding with tight tolerance control

Technical characteristics / specifications

• Base polymer: Polyamide-imide (PAI)
• Operating temperature range: -200°C to +290°C
• Typical mechanical strength: 70 MPa
• Manufacturing methods: Hot compression molding; Injection molding
• Tolerance control (injection molded parts): ±40 μm
• Indicative production capacity: >4 M/yr
• Defects program target: 0 ppm
• Typical injection molding diameter range: 2 mm to 200 mm
• Noted properties: high fatigue resistance, excellent wear resistance, chemical compatibility with many automotive and industrial fluids
