Rod PTFE Rulon® 488

sheettubeaeronautical

Overview
Rulon® 488 is a dull-turquoise, PTFE-based fluoropolymer developed for sliding and bearing applications, notably in veneer dryer bearings and gas compressor service. It delivers superior wear performance in extremely dry environments, broad chemical resistance and enhanced load capacity compared with Rulon® J and Rulon® 142.

Material & Processing
The material is a filled PTFE composite supplied as compression-molded stock and precision machined parts. Common manufacturing process: compression molding; finished components are molded or precision-machined to specification.

Typical offerings & applications

• Automatically molded bearings and components
• Sleeve, flanged and thrust bearings
• Stamped and formed seals
• Extruded shapes
• Machined parts and molded shapes

Typical applications include pumps, mixers, compressors (hydrogen and natural gas), household appliances, electrical insulators, linear slides, pipe supports and wear bands. Suitable for steam, wet, dry and vacuum environments.

Key performance characteristics

• Excellent wear resistance in extremely dry environments
• Near-universal chemical resistance (resists corrosives and trace acids)
• Higher load capacity than Rulon® J
• Better abrasion resistance than Rulon® J and Rulon® 142
• Well-suited for hydrogen and natural gas compressor applications

Standard Specifications
Materials: dull turquoise fluoropolymer, engineered organic filled
Service conditions: Temperature range: -240°C to +288°C
Mechanical strength: 6.9 MPa
Manufacturing process: Compression molding
Features: Friction coefficient: 0.10–0.30
Max PV (dry/lubricated): 0.35 MPa·m/s
Dimensions: Rods & Tubes: Ø 1.2 m × L 3 m
Sheets: 610 mm × 80 mm
Tapes: W 1 m × T = 0.08–6 mm

Additional performance notes

• Superior dry friction properties
• Stick/slip elimination
• Reduced hardware abrasion
• Minimal moisture absorption
• Dimensional stability in aggressive chemicals

Technical specifications

• Material type: PTFE and filled PTFE composites
• Color/appearance: Dull turquoise fluoropolymer, engineered organic filled
• Temperature range: -240°C to +288°C
• Mechanical strength: 6.9 MPa
• Manufacturing: Compression molding; molded and precision machined parts available
• Friction coefficient: 0.10–0.30
• Maximum PV (dry/lubricated): 0.35 MPa·m/s
• Available forms/dimensions: Rods & Tubes (Ø 1.2 m × L 3 m), Sheets (610 mm × 80 mm), Tapes (W 1 m; T 0.08–6 mm)
• Typical components: Molded bearings, sleeve/flanged/thrust bearings, stamped/formed seals, extruded shapes, machined parts
• Typical applications: Pumps, mixers, compressors, appliances, insulators, linear slides, pipe supports, wear bands
