Rod PTFE Rulon® 945

sheettubeaeronautical

Product Overview
Rulon® 945 is a black, carbon‑filled PTFE bearing material engineered for applications requiring minimal wear and deformation under load. It offers the lowest deformation among Rulon® grades, excellent chemical resistance and stable dimensions at elevated temperatures. Due to its moderate abrasiveness, Rulon® 945 is recommended for use against hard counterfaces such as hardened steel. It is not intended for applications that require electrical insulation.

Key Properties

• Very low wear and deformation under load
• Lowest deformation among Rulon® grades
• Excellent chemical resistance
• Good dimensional stability at temperature
• Moderate abrasive characteristics — best paired with hard mating surfaces (e.g., hardened steel)
• Not suitable where electrical insulation is required

Standard Specifications
Materials: Black fluoropolymer, carbon-filled
Service conditions: Temperature range −240°C to +288°C; Mechanical strength 8.3 MPa
Manufacturing: Compression molding
Tribology: Friction coefficient 0.20–0.35; Max PV (dry/lubricated) 0.35 MPa·m/s
Typical dimensions: Rods & tubes (Ø 1.2 m × L 3 m); Sheets (610 mm × 80 mm); Tapes (W 1 m × T 0.086–6 mm)

Forms & Typical Offerings
Available as molded bearings and components, sleeve, flanged and thrust bearings, stamped and machined seals, extruded profiles and machined parts. Common applications: pumps, mixers, compressors, appliances, insulators, linear slides, pipe supports and wear bands. Suitable for steam, wet and dry environments.

Performance Highlights

• Superior dry friction properties
• Reduction or elimination of stick–slip
• Reduced hardware abrasion
• Minimal moisture absorption
• Dimensional stability in aggressive chemicals

Technical Specifications

• Material: Black fluoropolymer, engineered carbon-filled
• Temperature range: −240°C to +288°C
• Mechanical strength: 8.3 MPa
• Friction coefficient: 0.20–0.35
• Max PV (dry/lubricated): 0.35 MPa·m/s
• Manufacturing process: Compression molding
• Available forms: rods & tubes, sheets, tapes, molded bearings, extruded shapes, machined parts
• Dimensions (provided): Rods & tubes: Ø 1.2 m × L 3 m; Sheets: 610 mm × 80 mm; Tapes: W 1 m × T 0.086–6 mm
• Typical applications: pumps, mixers, compressors, appliances, insulators, linear slides, pipe supports, wear bands
• Notes: Moderate abrasive qualities — best against hard mating surfaces; not suitable where electrical insulation is required
