Airport runway sweeper CMT90

for airportride-onfor snow

Product overview
The CMT90 runway snow sweeper, mounted on the T90 multi-functional chassis, is designed for maintenance of runways, taxiways and aprons. It clears light snow, slush, ice fragments and rubber residue while operating in confined airport service lanes.

Key features

• Large tiltable front rotary broom with rigid wear-resistant bristles for wide lateral cleaning in a single pass
• Fully enclosed insulated operator cabin with multifunction lighting and amber warning beacon for low-light operation
• Rear hopper compatible with sand or salt spreading for deicing
• Flexible hydraulic linkage for rapid broom height adjustment on uneven surfaces
• Heavy-duty deep-tread tires for traction on icy pavements
• Compact, highly maneuverable design for narrow service lanes and tight turning radii

Technical specifications

• Model: CMT90
• Brand: Cheerong
• Chassis model: T90 Multi-Functional Chassis
• Overall dimensions (L×W×H): 4350 × 1450 × 2250 mm
• Curb weight: 3000 kg
• Maximum gross weight: 4500 kg
• Wheelbase: 1830 mm
• Engine model: TD2011 L04w
• Rated power: 68 kW
• Emission standard: EU Stage IIIA
• Noise level: ≤88 dB
• Maximum travel speed: 30 km/h
• Maximum gradeability: ≥25%
• Braking distance: ≤5 m
• Minimum turning radius: 3.6 m

Applications

• Runway, taxiway and apron snow and debris removal at airports
• Winter maintenance of airside service roads and narrow operational lanes

Compliance and operation

• Low-emission, high-torque diesel engine complying with airport ground support safety requirements
• Insulated operator cabin provides windproof and frostproof protection for safe shift work in cold conditions
