Electric actuator ATS3600
linearfor aircraftstepper

electric actuator
electric actuator
Add to favorites
Compare this product


Characteristics

Type
electric
Movement
linear
Applications
for aircraft
Technology
stepper, screw
Stroke

Min.: 100 mm
(3.937 in)

Max.: 400 mm
(15.748 in)

Description

Design Features Large, clear aperture Travel range from 100 mm x 100 mm to 400 mm x 400 mm High-performance linear motion guides 15 arc sec orthogonality Noncontact linear encoder for high accuracy The demand for a high accuracy, robust, open-frame stage is met with the ATS3600. This dual-axis, large aperture, open-frame stage addresses the unique needs of scanning microscopy, wafer and printed circuit board inspection and automated assembly. Design and Construction Unlike other designs that are assembled from several discrete pieces, the ATS3600 is a three-piece design. This allows critical components such as orthogonality, straightness and flatness to be controlled during the initial machining, resulting in a stage with exceptional geometrical tolerances and inherent orthogonality.
