Air cargo pallet CM-AGE-AP

Overview
The aviation PAG pallet is a mainstream standard air cargo ULD widely deployed for wide-body aircraft freight transport. It features overall dimensions of 88'' × 125'', a tare weight of 92 kg and an impressive maximum gross weight of 6804 kg, delivering outstanding load capacity for heavy air freight shipments.
Manufactured with premium aerospace-grade aluminum alloys, its pallet frame adopts AL7003, the pallet sheet uses AL7021, and corner connections are built from AL2A14. This robust lightweight construction provides excellent impact resistance and long service life amid repeated stacking and ground handling operations.
Compliant with CAAC TSO‑C90c, FAA TSO‑C90c and NAS3610‑2A4P standards, the PAG pallet meets global civil aviation specifications. Reinforced corner structures enhance stability during loading and transit. It is a trusted unit load device for airlines, ground handlers and freight forwarders to streamline international air cargo logistics.

Key specifications

• Model: CM-AGE-AP
• Brand: CHEERSMETAL
• IATA code: PAG
• ATA code: P1
• NAS code: 2A4P
• Typical loading capacity: 6804 kg
• Typical dimension (example): 2235 mm (L) × 3175 mm (W)
• Certifications: CAAC, FAA
• Applicable aircraft: B747, B777, B747F, Airbus types and other compatible models

Available models & dimensions

• XD21 — IATA/ATA/NAS: PAG / P1 / 2A4P — Dimension: 2235 mm (L) × 3175 mm (W) — Max capacity: 6804 kg
• XD22 — PMC/P6/2M3P — Dimension: 2438 mm (L) × 3175 mm (W) — Max capacity: 6804 kg
• XD23 — PLA/P9/2L3P — Dimension: 1534 mm (L) × 3175 mm (W) — Max capacity: 3175 kg
• XD24 — PKC/-/2K3P — Dimension: 1562 mm (L) × 1534 mm (W) — Max capacity: 1588 kg
• XD25 — FQA — Dimension: 2438 mm (L) × 1534 mm (W) — Max capacity: 2450 kg

Compatibility & installation
Designed to integrate with standard aircraft cargo track and locking systems. Pallet interfaces follow IATA/ATA/NAS specifications; installation requires certified handling equipment and trained ground personnel. For specific aircraft compatibility, provide aircraft type and configuration to verify fit and certification requirements.

Logistics, delivery & warranty
Standard production lead time depends on order quantity; typical manufacturing and delivery time is 1–2 months after order confirmation. Packaging is adapted for air/sea transport. Standard warranty: 1 year. Payment terms commonly 30% T/T in advance, balance prior to shipment.

Images & documentation
Detailed product images, dimensional drawings, load plans and certification documents available on request. Contact us for CAD files and inspection reports.

FAQ (selected)

• Q: Are you a trading company or manufacturer? A: We are a factory.
• Q: How long is the delivery time? A: Typically 1–2 months depending on quantity.
• Q: Do you provide samples? A: No samples; standard warranty is one year.
• Q: What are the payment terms? A: 30% T/T in advance, balance before shipment.

Technical characteristics

• Model series: CM-AGE-AP
• Brand: CHEERSMETAL
• Name variants: Aircraft Transport Pallet; Aviation PAG Pallet; Metal Pallet
• Type: Aircraft pallet compliant with IATA/ATA/NAS codes
• Codes: IATA PAG / ATA P1 / NAS 2A4P
• Example loading capacity: 6804 kg
• Example dimension: 2235 mm (L) × 3175 mm (W)
• Certification: CAAC, FAA
• Applicable aircraft: B747, B777, B747F, Airbus and other compatible models
• Other available models: XD21, XD22, XD23, XD24, XD25
• Standard warranty: 1 year
